Denon AVR-4208 Service Manual

45
AVR-4802/AVC-A11SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
C107,108 254 4573 981 Electrolytic 10 µ F/50V CE04W1H100MT(RE3)
C111-114 256 1058 955 Metalized 0.068 µ F/50V CF93A1H683JT (JL)
C115,116 254 4573 949 Electrolytic 1
µ F/50V CE04W1H010MT(RE3)
C117-148 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101JT
AVC MODEL ONLY
C149,150 254 4573 981 Electrolytic 10
µ F/50V CE04W1H100MT(RE3)
AVC MODEL ONLY
C151-154 254 4313 918 Electrolytic 10
µ F/50V CE04W1H100MT(ASF)
C155-170 254 4573 981 Electrolytic 10 µ F/50V CE04W1H100MT(RE3)
C193,194 254 4569 911 Electrolytic 47 µ F/25V CE04W1E470MT(RE3)
AVC MODEL ONLY
C195-198 254 4313 934 Electrolytic 47
µ F/25V CE04W1E470MT(ASF)
C199-214 254 4569 911 Electrolytic 47 µ F/25V CE04W1E470MT(RE3)
C215 257 0511 917 Ceramic chip 0.022 µ F/50V CK73F1H223ZT
AVR MODEL ONLY
247 2018 903 Carbon chip 0 ohm 1/16W RM73B—0R0KT
AVC MODEL ONLY
C216 254 4313 963 Electrolytic 1 µ F/50V CE04W1H010MT(ASF)
AVR MODEL ONLY
C217,218 257 0511 917 Ceramic chip 0.022 µ F/50V CK73F1H223ZT
AVR MODEL ONLY
247 2018 903 Carbon chip 0 ohm 1/16W RM73B—0R0KT
AVC MODEL ONLY
C219 254 4313 963 Electrolytic 1 µ F/50V CE04W1H010MT(ASF)
AVR MODEL ONLY
C220 257 0511 917 Ceramic chip 0.022 µ F/50V CK73F1H223ZT
AVR MODEL ONLY
247 2018 903 Carbon chip 0 ohm 1/16W RM73B—0R0KT
AVC MODEL ONLY
C221 254 4313 963 Electrolytic 1 µ F/50V CE04W1H010MT(ASF)
AVR MODEL ONLY
C222,223 257 0511 917 Ceramic chip 0.022 µ F/50V CK73F1H223ZT
AVR MODEL ONLY
247 2018 903 Carbon chip 0 ohm 1/16W RM73B—0R0KT
AVC MODEL ONLY
C224 256 1059 996 Metalized 1 µ F/50V CF93A1H104JT
C231-236 254 4538 913 Electrolytic 22 µ F/16V CE04W1C220MT SMG/RE3
C237,238 254 4524 985 Electrolytic 10 µ F/50V CE04W1H100MT SMG/RE3
C239,240 254 4573 981 Electrolytic 10uF/50V CE04W1H100MT(RE3)
C301,302 254 4313 918 Electrolytic 10 µ F/50V CE04W1H100MT(ASF)
C307,308 254 4573 949 Electrolytic 1 µ F/50V CE04W1H010MT(RE3)
C309,310 254 4313 989 Electrolytic 33 µ F/50V CE04W1H330MT(ASF)
C311,312 254 4313 921 Electrolytic 22 µ F/50V CE04W1H220MT(ASF)
C313,314 254 4313 918 Electrolytic 10 µ F/50V CE04W1H100MT(ASF)
C319,320 254 4573 949 Electrolytic 1 µ F/50V CE04W1H010MT(RE3)
C321,322 254 4313 989 Electrolytic 33 µ F/50V CE04W1H330MT(ASF)
C323,324 254 4313 921 Electrolytic 22 µ F/50V CE04W1H220MT(ASF)
C325,326 254 4313 918 Electrolytic 10 µ F/50V CE04W1H100MT(ASF)
C331,332 254 4573 949 Electrolytic 1 µ F/50V CE04W1H010MT(RE3)
C333,334 254 4313 989 Electrolytic 33 µ F/50V CE04W1H330MT(ASF)
C335,336 254 4313 921 Electrolytic 22 µ F/50V CE04W1H220MT(ASF)
C337,338 254 4313 918 Electrolytic 10 µ F/50V CE04W1H100MT(ASF)
C343,344 254 4573 949 Electrolytic 1 µ F/50V CE04W1H010MT(RE3)
R703 247 2004 975 Carbon chip 75 ohm 1/16W RM73B—750JT
R704 247 2005 945 Carbon chip 150 ohm 1/16W RM73B—151JT
R705 247 2004 975 Carbon chip 75 ohm 1/16W RM73B—750JT
R706 247 2005 945 Carbon chip 150 ohm 1/16W RM73B—151JT
R707 247 2004 975 Carbon chip 75 ohm 1/16W RM73B—750JT
R708 247 2005 945 Carbon chip 150 ohm 1/16W RM73B—151JT
R709 247 2004 975 Carbon chip 75 ohm 1/16W RM73B—750JT
R710 247 2005 945 Carbon chip 150 ohm 1/16W RM73B—151JT
R711 247 2004 975 Carbon chip 75 ohm 1/16W RM73B—750JT
R712 247 2005 945 Carbon chip 150 ohm 1/16W RM73B—151JT
R713 247 2004 975 Carbon chip 75 ohm 1/16W RM73B—750JT
R714 247 2005 945 Carbon chip 150 ohm 1/16W RM73B—151JT
R715 247 2004 975 Carbon chip 75 ohm 1/16W RM73B—750JT
R716 247 2005 945 Carbon chip 150 ohm 1/16W RM73B—151JT
R717-726 247 2010 969 Carbon chip 22 kohm 1/16W RM73B—223JT
R727-736 247 2004 975 Carbon chip 75 ohm 1/16W RM73B—750JT
R737-744 247 2005 945 Carbon chip 150 ohm 1/16W RM73B—151JT
R745,746 247 2008 913 Carbon chip 2 kohm 1/16W RM73B—202JT
R749,750 247 2009 983 Carbon chip 10 kohm 1/16W RM73B—103JT
R751,752 247 2005 903 Carbon chip 100 ohm 1/16W RM73B—101JT
R753,754 247 2008 913 Carbon chip 2 kohm 1/16W RM73B—202JT
R757,758 247 2009 983 Carbon chip 10 kohm 1/16W RM73B—103JT
R759,760 247 2005 903 Carbon chip 100 ohm 1/16W RM73B—101JT
R761,762 247 2008 913 Carbon chip 2 kohm 1/16W RM73B—202JT
R765,766 247 2009 983 Carbon chip 10 kohm 1/16W RM73B—103JT
R767,768 247 2005 903 Carbon chip 100 ohm 1/16W RM73B—101JT
R769,770 247 2008 913 Carbon chip 2 kohm 1/16W RM73B—202JT
R773,774 247 2009 983 Carbon chip 10 kohm 1/16W RM73B—103JT
R775,776 247 2005 903 Carbon chip 100 ohm 1/16W RM73B—101JT
R777,778 247 2008 913 Carbon chip 2 kohm 1/16W RM73B—202JT
R781,782 247 2009 983 Carbon chip 10 kohm 1/16W RM73B—103JT
R783,784 247 2005 903 Carbon chip 100 ohm 1/16W RM73B—101JT
R785,786 247 2004 920 Carbon chip 47 ohm 1/16W RM73B—470JT
R787,788 247 2006 986 Carbon chip 560 ohm 1/16W RM73B—561JT
R789 247 2010 927 Carbon chip 15 kohm 1/16W RM73B—153JT
R791,792 247 2006 960 Carbon chip 470 ohm 1/16W RM73B—471JT
R793,794 247 2009 983 Carbon chip 10 kohm 1/16W RM73B—103JT
R795-798 247 2005 903 Carbon chip 100 ohm 1/16W RM73B—101JT
R799,800 247 2009 983 Carbon chip 10 kohm 1/16W RM73B—103JT
R801 247 2006 973 Carbon chip 510 ohm 1/16W RM73B—511JT
R802 247 2006 960 Carbon chip 470 ohm 1/16W RM73B—471JT
R803 247 2006 999 Carbon chip 620 ohm 1/16W RM73B—621JT
R804 247 2006 986 Carbon chip 560 ohm 1/16W RM73B—561JT
R805 247 2010 901 Carbon chip 12 kohm 1/16W RM73B—123JT
R807 247 2002 964 Carbon chip 10 ohm 1/16W RM73B—100JT
CAPACITORS GROUP
C101 254 4538 900 Electrolytic 10 µ F/16V CE04W1C100MT SMG/RE3
C102 255 1265 965 Mylar film 0.018 µ F/50V CQ93M1H183JT (B)
C103 256 1058 997 Metalized 0.15 µ F/50V CF93A1H154JT (JL)
C104 256 1058 955 Metalized 0.068 µ F/50V CF93A1H683JT (JL)
