AVR-4802/AVC-A11SR
Front Chassis
Front Chassis, H/P P.W.B.
(1) Remove 8 screws
18
.
(2) Detach the Front Chassis by pulling upward to release
4 hooks.
(3) Remove 2 screws
19
and snap plate, then detach the
H/P P.W.B.
Hook
18
18
18
Hook
19
19
Snap Plate
H/P P.W.B.
