104
AVR-1707/1507/687/587/487
4 00D 963 0214 704 WINDOW DISPLAY
1707E2,1507E2
5077211922090S 1
4 00D 963 0292 001 WINDOW DISPLAY
1507E3,587E3
50772119220B0S 1 *
4 00D 963 0292 108 WINDOW DISPLAY
487E3
50772119220C0S 1 *
5 00D 963 0190 200 COVER RCA
1707E3,687E3
4317211701000S 1
5 00D 963 0190 307 COVER RCA
1707E2,1507E2
4317211701100S 1
5 00D 963 0138 107 COVER RCA
1507E3,587E3,487E3
4317211691000S 1
6 00D 963 0138 806 KNOB VOLUME
Black
5087210981000S 1
6 00D 963 0240 406 KNOB VOLUME
Premium Silver
5087210981110S 1
6 00D 963 0138 903 KNOB VOLUME
Silver
5087210981100S 1
7 00D 963 0138 505 KNOB SELECT
Black
5087210971000S 1
7 00D 963 0240 309 KNOB SELECT
Premium Silver
5087210971110S 1
7 00D 963 0138 602 KNOB SELECT
Silver
5087210971100S 1
8 nsp 00D 963 0138 000 BRACKET SIDE L/R 4010211986000S 2
9 00D 963 0137 807 LENS STANDBY 3710210503000S 1
10 00D 963 0184 106 BUTTON STANDBY
Black
5097212368000SZ 1
10 00D 963 0221 904 BUTTON STANDBY
Premium Silver
5097212368030SZ 1
10 00D 963 0190 501 BUTTON STANDBY
Silver
5097212368010SZ 1
11 00D 963 0184 009 BUTTON POWER
Black
5097212358000SZ 1
11 00D 963 0230 005 BUTTON POWER
Premium Silver
5097212358300SZ 1
11 00D 963 0194 002 BUTTON POWER
Silver
5097212358100SZ 1
12 00D 960 0191 417 LENS LED 3710210043001S 2
17 00D 963 0094 801 BUTTON 3KEY(A) 5090211741000S 4
22 00D 963 0139 407 BUTTON 4KEY
Black
5097212341000S 1
22 00D 963 0249 009 BUTTON 4KEY
Premium Silver
5097212341110S 1
22 00D 963 0139 504 BUTTON 4KEY
Silver
5097212341100S 1
23 00D 963 0139 106 BUTTON 3KEY
Black
5097212331000S 2
23 00D 963 0248 903 BUTTON 3KEY
Premium Silver
5097212331110S 2
23 00D 963 0139 203 BUTTON 3KEY
Silver
5097212331100S 2
26 nsp 00D 960 0184 301 BRACKET HEAT SINK-F 4010210396000S 1
27 00D 963 0044 107 TR PNP 2SB1560-Y
Q102C Q102FL Q102FR
Q102SL Q102SR
J5011560Y0000P 5
28 00D 960 0187 900 POSISTOR P43T7D330BW16 F320161001020S 1
29 00D 963 0280 107 TR NPN 2SC3964
Q103C Q103FL Q103FR
Q103SL Q103SR
J502396400000S 5
30 00D 963 0247 108 CABINET TOP
Black
3000210096400S 1
30 00D 963 0247 205 CABINET TOP
Silver,Premium Silver
3000210096500S 1
31 00D 963 0044 204 TR NPN 2SD2390-Y
Q101C Q101FL Q101FR
Q101SL Q101SR
J5032390Y0000P 5
32 nsp - HEAT SINK MAIN 2120210928000S 1
33 nsp 00D 960 0184 204 BRACKET HEAT SINK-B 4010210386000S 1
34 nsp 00D 963 0101 600 BRACKET PCB 4010210186000S 2
39 nsp 00D 963 0092 609 BRACKET TRANS 4010210466002S 1
! 40 00D 963 0301 206 POWER TRANS
1707E3,687E3
8200960660140S 1 *
! 40 00D 963 0301 303 POWER TRANS
1707E2
8200960660020S 1 *
! 40 00D 963 0301 400 POWER TRANS
1707EUT
8200960660050S 1 *
! 40 00D 963 0301 507 POWER TRANS
1507E3,587E3,487E3
8200960660160S 1 *
! 40 00D 963 0301 604 POWER TRANS
1507E2
8200960660060S 1 *
49 nsp 00D 960 0192 403 STOPPER CORD AC 4380210002000S 1
! 50 00D 963 0292 205 AC CORD
1507E3,587E3,487E3
L068125100020S 1 *
! 50 00D 963 0292 302 AC CORD
1707EUT
L068125110000S 1 *
! 50 00D 963 0292 409 AC CORD
1707E2,1507E2
L068250250040S 1 *
51 nsp 00D 963 0292 506 CHASSIS MAIN 3200210146305S 1 *
52 nsp 00D 963 0137 904 FOOT 4007210261000S 4
53 nsp 00D 963 0214 607 CUSHION FOOT 4050211295000S 4
54 nsp 00D 963 0191 403 CUSHION SIDE 4050211095000S 2
56 nsp 00D 960 0003 301 SUPPORTER PCB 4070001601010S 4
57 nsp 00D 960 0184 107 BRACKET SUPPORTER 4010210206000S 1
58 nsp - SUPPORTER P.C. 4070210192000S 1
Ref. No. nsp Part No. Part Name Remarks ETRO Q'ty New
