Denon AVR-487 Service Manual

105
AVR-1707/1507/687/587/487
70 00D 963 0145 608 TUNER PACK
1507E3,587E3,487E3
E903014000020F 1
70 00D 216 0125 001 TUNER PACK
1707EUT
1
70 00D 216 0125 001 TUNER PACK
1707E2,1507E2
1
71 nsp 00D 963 0292 506 CHASSIS BACK
1707E3
3207211826000S 1 *
71 nsp 00D 963 0292 603 CHASSIS BACK
687E3
3207211826300S 1 *
71 nsp 00D 963 0292 700 CHASSIS BACK
587E3
3207211826310S 1 *
71 nsp 00D 963 0292 807 CHASSIS BACK
1707EUT
3207211826200S 1 *
71 nsp 00D 963 0292 904 CHASSIS BACK
1707E2
3207211826100S 1 *
71 nsp 00D 963 0293 000 CHASSIS BACK
1507E2
3207211826110S 1 *
71 nsp 00D 963 0293 107 CHASSIS BACK
1507E3
3207211826010S 1 *
71 nsp 00D 963 0293 204 CHASSIS BACK
487E3
3207211826A00S 1 *
72 nsp 00D 963 0293 301 SHEET CABINET 1210210235000S 1
73 nsp 00D 963 0120 306 BRACKET SIDE
1707E2,1507E2,1707EUT
4010210686000S 1
80 nsp - WASHER B300035161P10S 1 *
82 nsp - CUSHION PWB TOP
1507E3
4050211085000S 1 *
84 nsp 00D 963 0192 703 COVER SAFETY
1707E2,1507E2,1707EUT
4310212122000S 1
85 nsp 00D 449 0139 105 COVER HOLDER
1707E2,1507E2,1707EUT
6
★
nsp - LICENSE LABEL(DOLBY/DTS)
1507E3,587E3,487E3,1707EUT
5507030000311S 1
★
nsp -
LABEL ORIGIN (BACK CHASSIS) 1707EUT
5507003020021S 1
★
nsp - LABEL RATING
1707EUT
5507030000480S 1 *
★
nsp 00D 513 3333 005 LABEL (TRANS) 1 *
★
nsp 00D 963 0193 003 CABLE,FLAT CARD 1.25MM N712151544811S 1
★
nsp 00D 963 0161 501 CABLE,FLAT CARD 1.25MM N712232034810S 1
SCREWS
A nsp 00D 963 0018 007
SCREW(3X8 B-TYPE ZNY/BH)
B020030081B10S 63
B nsp 00D 960 9008 420
SCREW(3X8 ZnY WASHER PI12)
1500001456010S 4
C nsp 00D 963 9004 054
SCREW(3X15 B-TYPE ZNY/BH)
B020030151B10S 2
D nsp 00D 960 0108 701
SCREW(3X10 B-TYPE(DOT) BK/BH)
B020030103B11S 36
E nsp 00D 963 9006 175
SCREW(3X14 P+S-WASHER ZNY/HH)
B018230141H11S 22
F nsp 00D 963 0018 104
SCREW(3X17 B-TYPE ZNY/BH)
B020030171B10S 3
G 00D 963 0048 307
SCREW(4X8 B-TYPE(DOT) BK/BH) Black
1500040083B10S 6
G 00D 963 9004 012
SCREW(4X8 B-TYPE(DOT) NI/BH) Silver,Premium Silver
1500040084B10S 6
H nsp 00D 960 9009 610
SCREW(4X10 P+S-WASHER ZNY/BH)
B028940101B10S 1
I nsp 00D 963 0136 701
SCREW(3X8 BK WASHER PI12)
1500001456020S 1
J nsp 00D 963 0232 702
SCREW(4X6 S-TYPE ZNY/BH)
B020740061B10S 6
K nsp 00D 963 0232 605
SCREW(3X5 B-TYPE ZNY/BH)
B020030051B10S 2
L nsp 00D 963 0136 507
SCREW(3X8 PI9.5 B-TYPE ZNY)
1500001206010S 2
