Denon AVR-487 Service Manual

55
AVR-1707/1507/687/587/487
C502FR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C502SBL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C502SBR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C502SL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C502SR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C503C 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503FL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503FR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503SBL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503SBR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503SL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503SR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504C 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504FL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504FR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504SBL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504SBR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504SL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504SR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C505C 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505FL 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505FR 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505SBL 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505SBR 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505SL 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505SR 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C506C 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506FL 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506FR 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506SBL 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506SBR 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506SL 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506SR 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C507C 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507FL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507FR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507SBL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507SBR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507SL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507SR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
OTHERS PARTS GROUP
BKT501 nsp 00D 960 0184 000 BRACKET SCREW 4010210196000S
BKT503 nsp 00D 960 0184 000 BRACKET SCREW 4010210196000S
CN102X nsp 00D 963 0256 306 CN,WIRE 90MM/5P 1707E3,687E3 L000900050030F
CN501 nsp 00D 963 0205 700 CN.WAFER 5P L101100030510S
CN502 nsp 00D 963 0086 505 CN.WAFER 7P L101100030710S
CN503 nsp 00D 963 0205 700 CN.WAFER 5P L101100030510S
CN504 nsp 00D 963 0085 506 CN.WAFER 9P L101100030910S
CN505 nsp 00D 963 0236 902 CN.WAFER 12P L101100031210S
CN506T nsp 00D 963 0245 401 CN,WIRE 140MM/15P 1707E3,687E3 L000141150030F
CN506T 00D 963 0159 704 CN,WIRE 140MM/15P 1707EUT L000141150020P
CP101X nsp 00D 960 0123 207 CN.WAFER 3P 1707E3,687E3 L102526700300S
CP506 nsp 00D 963 0060 703 CN.WAFER 15P L101220150000S
CP513 nsp 00D 963 0066 101 CN.WAFER 5P L101220050000S
CP558 00D 963 0253 406 CN.WAFER 14P L101220140000S
CP992 nsp 00D 960 0217 553 CN.WAFER 4P L102526700400S
L101SBL nsp 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000F
L101SBR nsp 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000F
TP106,107 nsp 00D 963 0207 203 CN.WAFER 3P L101530150310S
Ref. No. nsp Part No. Part Name Remarks Q'ty New
