Denon AVR-487 Service Manual

56
AVR-1707/1507/687/587/487
CNT P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC551,552 00D 963 0218 807 IC BU4094BCF J040140940030P
Q551 00D 960 0196 700 TR KTC3200BL J5023200B0050S
Q552 00D 960 0196 302 TR KTA1268BL J5001268B0050S
Q553-556 00D 963 0120 704 TR KRA102S J520010200210S
Q570A 00D 963 0148 508 TR KTA1504S J520015040150S
Q570B 00D 963 0121 606 TR KRC107S J522107S00210S
Q571X 00D 963 0121 606 TR KRC107S J522107S00210S
Q572X 00D 963 0148 508 TR KTA1504S J520015040150S
Q573C 00D 963 0121 004 TR KRC104M J502104000010S
D501D 00D 963 0058 407 D,SWITCHING IN4007 K000400700520S
D551-561 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D562,563 00D 963 0058 407 D,SWITCHING IN4007 K000400700520S
D565-567 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D568-571 00D 963 0058 407 D,SWITCHING IN4007 K000400700520S
D572X 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D573X 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D574C 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
ZD564 00D 960 0095 500 D,ZENER MTZJ5.1B K06005R144520S
RESISTORS GROUP
R559 00D 960 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S
R565 00D 960 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S
R570 00D 960 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S
R575,576 00D 963 0216 003 R,METAL FILM 0.22-J,1W C060R22065050S
R577C 00D 963 0236 203 R,METAL FILM 180-J,1/4W C060018163050S
CAPACITORS GROUP
C280 00D 963 0021 104 C,ELECT 6800UF-M/16V D040682083000F
C280A 00D 963 0224 804 C,ELECT 3300UF-M/25V D040332084010F
C281 00D 963 0224 804 C,ELECT 3300UF-M/25V D040332084010F
C551 00D 963 0294 106
C,ELECT 2.2UF-M/50V (Pb Free)
1707E3,687E3,1707EUT D0402R2087160F
C551 00D 960 9009 940 C,ELECT 1000UF-M/16V 1707E2 D040102083030F
C551C nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C551G nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C551S 00D 963 0225 609 C,CERAMIC 0.047UF-Z/50V D005473597520S
C555,556 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
C557 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C559-561 00D 963 0145 006 C,FILM 0.047UF-J/50V D020473167050P
C563X 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C564X nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C565X 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C566X nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C567X nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C568X nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C569X nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C570X nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
OTHERS PARTS GROUP
CN202X nsp 00D 963 0256 005 CN,WIRE 350MM/8P 1707E3,687E3 L000351080010F
CN552 nsp 00D 963 0097 303 CN.WAFER 15P L101100031510S
CN553 nsp 00D 963 0086 709 CN.WAFER 11P L101100031110S
CN554A 00D 963 0184 805 CN,WIRE 80MM/14P L000800140060P
CN554B 00D 963 0184 708 CN,WIRE 80MM/4P L000800040110P
CN555 nsp 00D 963 0110 701 CN.WAFER 14P L101100031410S
