Denon AVR-5803 Service Manual

79
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
C133,134 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C135-138 257 3013 933 Metallized chip 0.1uF/50V CF73=1H104J (ECHUC9)
C155,156 257 3012 921 Metallized chip 0.01uF/50V CF73=1H103J (ECHUB5)
C201,202 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
for E2,E1,E1C,EUT
C203,204 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C209,210 254 4492 907 Electrolytic 47uF/25V CE04W1E470M (ASF)
C211,212 254 4313 963 Electrolytic 1uF/50V CE04W1H010M (ASF)
C213,214 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
for E2,E1,E1C,EUT
C215,216 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C221,222 254 4492 907 Electrolytic 47uF/25V CE04W1E470M (ASF)
C225,226 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
for E2,E1,E1C,EUT
C227,228 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C233,234 254 4492 907 Electrolytic 47uF/25V CE04W1E470M (ASF)
C237,238 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
for E2,E1,E1C,EUT
C239,240 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C245,246 254 4492 907 Electrolytic 47uF/25V CE04W1E470M (ASF)
C249,250 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
for E2,E1,E1C,EUT
C251,252 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C257,258 254 4492 907 Electrolytic 47uF/25V CE04W1E470M (ASF)
C261,262 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
for E2,E1,E1C,EUT
C263,264 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C269,270 254 4492 907 Electrolytic 47uF/25V CE04W1E470M (ASF)
C273,274 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
for E2,E1,E1C,EUT
C275,276 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C281,282 254 4492 907 Electrolytic 47uF/25V CE04W1E470M (ASF)
C285,286 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
for E2,E1,E1C,EUT
C287,288 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C293,294 254 4492 907 Electrolytic 47uF/25V CE04W1E470M (ASF)
C295,296 254 4313 963 Electrolytic 1uF/50V CE04W1H010M (ASF)
C297 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C301,302 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C307-309 257 0511 917 Ceramic chip 0.022uF/50V CK73F1H223Z
for E2,E1,E1C,EUT
C311-314 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C317-320 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C321-324 255 1273 944 Mylar film 220pF/50V CQ93M1H221J (B)
C325,326 254 4313 934 Electrolytic 47uF/50V CE04W1H470M (ASF)
C327,328 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C329,330 254 4313 934 Electrolytic 47uF/50V CE04W1H470M (ASF)
C332 257 3010 907 Metallized chip 100pF/50V CF73=1H101J (ECHUB5)
C335,336 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C337,338 254 4313 934 Electrolytic 47uF/50V CE04W1H470M (ASF)
R945,946 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
R947,948 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R951-954 247 2011 942 Carbon chip 47kohm 1/16W RM73B--473J
R955,956 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
R957,958 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R961-964 247 2011 942 Carbon chip 47kohm 1/16W RM73B--473J
R965,966 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
R967,968 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R971-974 247 2011 942 Carbon chip 47kohm 1/16W RM73B--473J
R975,976 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
R977,978 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R981-988 247 2012 925 Carbon chip 100kohm 1/16W RM73B--104J
R997-999 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
RR101,102 247 2010 930 Carbon chip 16kohm 1/16W RM73B--163J
RR103 247 2010 969 Carbon chip 22kohm 1/16W RM73B--223J
RR105,106 247 2009 954 Carbon chip 7.5kohm 1/16W RM73B--752J
RR107,108 247 2010 930 Carbon chip 16kohm 1/16W RM73B--163J
RR109,110 247 2009 954 Carbon chip 7.5kohm 1/16W RM73B--752J
RR111 247 2009 909 Carbon chip 4.7kohm 1/16W RM73B--472J
RR113 247 2010 969 Carbon chip 22kohm 1/16W RM73B--223J
RR115 247 2009 909 Carbon chip 4.7kohm 1/16W RM73B--472J
RR121,122 247 2010 930 Carbon chip 16kohm 1/16W RM73B--163J
RR123-126 247 2009 909 Carbon chip 4.7kohm 1/16W RM73B--472J
RR127,128 247 2004 920 Carbon chip 47ohm 1/16W RM73B--470J
RR129,130 247 2012 925 Carbon chip 100kohm 1/16W RM73B--104J
RR141,142 247 2010 930 Carbon chip 16kohm 1/16W RM73B--163J
RR143-146 247 2009 909 Carbon chip 4.7kohm 1/16W RM73B--472J
RR147,148 247 2004 920 Carbon chip 47ohm 1/16W RM73B--470J
RR149,150 247 2012 925 Carbon chip 100kohm 1/16W RM73B--104J
RR154 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
RR157 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
RR162-170 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
CAPACITORS GROUP
C101,102 257 0507 934 Ceramic chip 220pF/50V CC73CH1H221J
C103 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C105,106 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
C107,108 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
C109,110 254 4536 931 Electrolytic 220uF/10V CE04W1A221M (SMG/RE3)
C111,112 255 4199 999 Mylar film 0.024uF/50V CQ92M1H243J (MRZ)
C113,114 255 1265 907 Mylar film 6800pF/50V CQ93M1H682J (B)
C115,116 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
C117,118 254 4313 963 Electrolytic 1uF/50V CE04W1H010M (ASF)
C119,120 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
for E2,E1,E1C,EUT
C121,122 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
for E2,E1,E1C,EUT
C123,124 257 0511 917 Ceramic chip 0.022uF/50V CK73F1H223Z
for E2,E1,E1C,EUT
C127,128 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
for E2,E1,E1C,EUT
