80
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
C339-342 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C345-348 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C349 255 1273 944 Mylar film 220pF/50V CQ93M1H221J (B)
C350 255 1273 944 Mylar film 220pF/50V CQ93M1H221K (B)
C351 255 1273 944 Mylar film 220pF/50V CQ93M1H221J (B)
C352 255 1273 944 Mylar film 220pF/50V CQ93M1H221K (B)
C353,354 254 4313 934 Electrolytic 47uF/50V CE04W1H470M (ASF)
C355,356 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C357,358 254 4313 934 Electrolytic 47uF/50V CE04W1H470M (ASF)
C363,364 254 4313 934 Electrolytic 47uF/50V CE04W1H470M (ASF)
C365-370 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C373-376 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C377-380 255 1273 944 Mylar film 220pF/50V CQ93M1H221J (B)
C381,382 254 4313 934 Electrolytic 47uF/50V CE04W1H470M (ASF)
C383,384 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C385,386 254 4313 934 Electrolytic 47uF/50V CE04W1H470M (ASF)
C391-398 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C401-404 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C405-408 255 1273 944 Mylar film 220pF/50V CQ93M1H221J (B)
C409-424 254 4313 918 Electrolytic 10uF/50V CE04W1H100M (ASF)
C425-440 257 0502 971 Ceramic chip 5pF/50V CC73CH1H5R0C
C451-458 257 3012 921 Metallized chip 0.01uF/50V
CF73=1H103J (ECHUB5)
C601,602 254 4313 976 Electrolytic 2.2uF/50V CE04W1H2R2M (ASF)
C605,606 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
C607,608 254 4313 905 Electrolytic 3.3uF/50V CE04W1H3R3M (ASF)
C609,610 257 3013 904 Metallized chip 0.056uF/50V
CF73=1H563J (ECHUC9)
C611,612 257 3012 905 Metallized chip 6800pF/50V
CF73=1H682J (ECHUB5)
C613,614 254 4524 943 Electrolytic 1uF/50V
CE04W1H010M (SMG/RE3)
C615,616 257 3012 934 Metallized chip 0.012uF/50V
CF73=1H123J (ECHUB5)
C617,618 257 3011 951 Metallized chip 2700pF/50V
CF73=1H272J (ECHUB5)
C619,620 257 3012 963 Metallized chip 0.022uF/50V
CF73=1H223J (ECHUB5)
C621,622 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C623,624 254 4313 976 Electrolytic 2.2uF/50V CE04W1H2R2M (ASF)
C627,628 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
C629,630 254 4313 905 Electrolytic 3.3uF/50V CE04W1H3R3M (ASF)
C631,632 257 3013 904 Metallized chip 0.056uF/50V
CF73=1H563J (ECHUC9)
C633,634 257 3012 905 Metallized chip 6800pF/50V
CF73=1H682J (ECHUB5)
C635,636 257 3012 934 Metallized chip 0.012uF/50V
CF73=1H123J (ECHUB5)
C637,638 257 3011 951 Metallized chip 2700pF/50V
CF73=1H272J (ECHUB5)
C639,640 257 3012 963 Metallized chip 0.022uF/50V
CF73=1H223J (ECHUB5)
C641,642 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C643,644 254 4313 976 Electrolytic 2.2uF/50V CE04W1H2R2M (ASF)
C647,648 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
C649,650 254 4313 905 Electrolytic 3.3uF/50V CE04W1H3R3M (ASF)
C651,652 257 3013 904 Metallized chip 0.056uF/50V
CF73=1H563J (ECHUC9)
C653,654 257 3012 905 Metallized chip 6800pF/50V
CF73=1H682J (ECHUB5)
C655,656 257 3012 934 Metallized chip 0.012uF/50V
CF73=1H123J (ECHUB5)
C657,658 257 3011 951 Metallized chip 2700pF/50V
CF73=1H272J (ECHUB5)
C659,660 257 3012 963 Metallized chip 0.022uF/50V
CF73=1H223J (ECHUB5)
C661,662 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C663,664 254 4313 976 Electrolytic 2.2uF/50V CE04W1H2R2M (ASF)
C667,668 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
C669,670 254 4313 905 Electrolytic 3.3uF/50V CE04W1H3R3M (ASF)
C671,672 257 3013 904 Metallized chip 0.056uF/50V
CF73=1H563J (ECHUC9)
C673,674 257 3012 905 Metallized chip 6800pF/50V
CF73=1H682J (ECHUB5)
C677,678 257 3012 934 Metallized chip 0.012uF/50V
CF73=1H123J (ECHUB5)
C679,680 257 3011 951 Metallized chip 2700pF/50V
CF73=1H272J (ECHUB5)
C681,682 257 3012 963 Metallized chip 0.022uF/50V
CF73=1H223J (ECHUB5)
C683,684 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C693 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C694 254 4524 956 Electrolytic 2.2uF/35V
CE04W1H2R2M (SMG/RE3)
C695 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C696 254 4538 939 Electrolytic 47uF/16V
CE04W1C470M (SMG/RE3)
C697 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C698,699 254 4524 943 Electrolytic 1uF/50V
CE04W1H010M (SMG/RE3)
C700 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C701,702 254 4524 943 Electrolytic 1uF/50V
CE04W1H010M (SMG/RE3)
C703-705 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C707-710 254 4524 943 Electrolytic 1uF/50V
CE04W1H010M (SMG/RE3)
C712 254 4522 958 Electrolytic 100uF/35V
CE04W1V101M (SMG/RE3)
C713-722 254 4313 963 Electrolytic 1uF/50V CE04W1H010M (ASF)
C801,802 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C803,804 254 4538 942 Electrolytic 100uF/16V
CE04W1C101M (SMG/RE3)
C807,808 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C809-812 254 4524 998 Electrolytic 22uF/50V
CE04W1H220M (SMG/RE3)
C815,816 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C817-820 254 4524 998 Electrolytic 22uF/50V
CE04W1H220M (SMG/RE3)
C823,824 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C825-828 254 4524 998 Electrolytic 22uF/50V
CE04W1H220M (SMG/RE3)
C831,832 254 4313 947 Electrolytic 4.7uF/50V CE04W1H4R7M (ASF)
C833-836 254 4524 998 Electrolytic 22uF/50V
CE04W1H220M (SMG/RE3)
C839 254 4524 943 Electrolytic 1uF/50V
CE04W1H010M (SMG/RE3)
C841,842 254 4347 748 Electrolytic 1uF/50V
CE04W1H010MC(ARSA)
C921,922 254 4313 963 Electrolytic 1uF/50V CE04W1H010M (ASF)
C941,942 254 4524 998 Electrolytic 22uF/50V
CE04W1H220M (SMG/RE3)
C943,944 254 4524 985 Electrolytic 10uF/50V
CE04W1H100M (SMG/RE3)
C951,952 254 4524 998 Electrolytic 22uF/50V
CE04W1H220M (SMG/RE3)
C953,954 254 4524 985 Electrolytic 10uF/50V
CE04W1H100M (SMG/RE3)
C955,956 257 3012 921 Metallized chip 0.01uF/50V
CF73=1H103J (ECHUB5)
C961,962 254 4524 998 Electrolytic 22uF/50V
CE04W1H220M (SMG/RE3)
C963,964 254 4524 985 Electrolytic 10uF/50V
CE04W1H100M (SMG/RE3)
C971,972 254 4524 998 Electrolytic 22uF/50V
CE04W1H220M (SMG/RE3)
C973,974 254 4524 985 Electrolytic 10uF/50V
CE04W1H100M (SMG/RE3)
C975,976 257 3012 921 Metallized chip 0.01uF/50V
CF73=1H103J (ECHUB5)
C981-988 254 4524 985 Electrolytic 10uF/50V
CE04W1H100M (SMG/RE3)
CC123,124 257 0504 940 Ceramic chip 33pF/50V CC73CH1H330J
CC127,128 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
CC129,130 254 4524 985 Electrolytic 10uF/50V
CE04W1H100M (SMG/RE3)
