Denon AVR-5803 Service Manual

87
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
RR502 247 2005 945 Carbon chip 150ohm 1/16W RM73B--151J
RR503 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
RR504 247 2005 945 Carbon chip 150ohm 1/16W RM73B--151J
RR505 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
RR506 247 2005 945 Carbon chip 150ohm 1/16W RM73B--151J
RR507 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
RR508 247 2005 945 Carbon chip 150ohm 1/16W RM73B--151J
RR509 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
RR510 247 2005 945 Carbon chip 150ohm 1/16W RM73B--151J
RR511 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
RR512 247 2005 945 Carbon chip 150ohm 1/16W RM73B--151J
RR513 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
RR514 247 2005 945 Carbon chip 150ohm 1/16W RM73B--151J
RR515 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
RR516 247 2005 945 Carbon chip 150ohm 1/16W RM73B--151J
RR517-526 247 2010 969 Carbon chip 22kohm 1/16W RM73B--223J
RR527-536 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
RR537-544 247 2005 945 Carbon chip 150ohm 1/16W RM73B--151J
RR545 247 2009 967 Carbon chip 8.2kohm 1/16W RM73B--822J
RR546 247 2007 969 Carbon chip 1.2kohm 1/16W RM73B--122J
RR547 247 2011 942 Carbon chip 47kohm 1/16W RM73B--473J
RR548 247 2005 987 Carbon chip 220ohm 1/16W RM73B--221J
RR549 247 2009 967 Carbon chip 8.2kohm 1/16W RM73B--822J
RR551,552 247 2009 909 Carbon chip 4.7kohm 1/16W RM73B--472J
RR553 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
RR554 247 2002 964 Carbon chip 10ohm 1/16W RM73B--100J
RR601 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
for E2,E1,E1C,EUT
RR602 247 2004 946 Carbon chip 56ohm 1/16W RM73B--560J
for E2,E1,E1C,EUT
RR603,604 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
for EU,EC
RR605,606 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
for E2,E1,E1C,EUT
RR617 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
RR620 247 2006 973 Carbon chip 510ohm 1/16W RM73B--511J
RR623 247 2006 986 Carbon chip 560ohm 1/16W RM73B--561J
RR627 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
RR629 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
RR631 247 2007 927 Carbon chip 820ohm 1/16W RM73B--821J
RR633 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
RR634 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
RR635 247 2008 913 Carbon chip 2kohm 1/16W RM73B--202J
RR638 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
RR639 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
RR640,641 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
RR642 247 2008 913 Carbon chip 2kohm 1/16W RM73B--202J
RR645 247 2008 913 Carbon chip 2kohm 1/16W RM73B--202J
RR648,649 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
RR650,651 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
VR601-603 211 6138 903 Semi fixed resistor 1kohm V03PB102M (RH03ADC)
CAPACITORS GROUP
C301 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C302 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C303 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C304 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C305 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C306-308 257 0504 940 Ceramic chip 33pF/50V CC73CH1H330J
C309 257 0510 918 Ceramic chip 3300pF/50V CK73B1H332K
C310,311 257 0503 941 Ceramic chip 12pF/50V CC73CH1H120J
C312 257 3014 987 Metallized chip 0.022uF/16V
CF73=1C223J (ECHUB5)
C313 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
C314 254 4572 908 Electrolytic 10uF/16V
CE67C1C100M (MV-B)
C315 257 0510 918 Ceramic chip 3300pF/50V CK73B1H332K
C316 257 0508 917 Ceramic chip 470pF/50V CC73CH1H471J
C317 254 4571 912 Electrolytic 1uF/50V CE67C1H010M (MV-B)
C318 257 3015 944 Metallized chip 0.068uF/16V CF73=1C683J (ECHUB5)
C319 254 4571 912 Electrolytic 1uF/50V CE67C1H010M (MV-B)
C320 257 0506 993 Ceramic chip 150pF/50V CC73CH1H151J
C321 257 3011 922 Metallized chip 1200pF/50V CF73=1H122J (ECHUB5)
C322 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C323 254 4464 906 Electrolytic 100uF/6.3V CE67C0J101M
C324 257 3011 919 Metallized chip 1000pF/50V CF73=1H102J (ECHUB5)
C325 254 4572 908 Electrolytic 10uF/16V CE67C1C100M (MV-B)
C327,328 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C329 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C330,331 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C332 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C334 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C336 254 4464 906 Electrolytic 100uF/6.3V CE67C0J101M
C337-340 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C341,342 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C345,346 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C347 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C348 254 4572 908 Electrolytic 10uF/16V CE67C1C100M (MV-B)
C351 254 4464 906 Electrolytic 100uF/6.3V CE67C0J101M
C352 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C353 254 4464 906 Electrolytic 100uF/6.3V CE67C0J101M
C354,355 257 3006 911 Metallized chip 0.1uF/16V CF73=1C104J (ECHUB5)
C356 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C501-504 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C505-512 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C513,514 254 4464 906 Electrolytic 100uF/6.3V CE67C0J101M
C517,518 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C519,520 254 4464 906 Electrolytic 100uF/6.3V CE67C0J101M
C522 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C524 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C526-533 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C535 257 0516 941 Ceramic chip 0.047uF/25V CK73B1E473K
C536 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
