AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
C537 257 0516 941 Ceramic chip 0.047uF/25V CK73B1E473K
C538 254 4571 912 Electrolytic 1uF/50V CE67C1H010M (MV-B)
C539 257 0516 941 Ceramic chip 0.047uF/25V CK73B1E473K
C566 254 4571 912 Electrolytic 1uF/50V
CE67C1H010M (MV-B)
C567-571 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
C635 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C655 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
C656 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C657-660 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C661 257 3006 953 Metallized chip 680pF/50V CF73=1H681J (ECHUB5)
C662-665 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C666,667 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
C668,669 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C670 254 4571 938 Electrolytic 0.47uF/50V CE67C1HR47M (MV-B)
C671,672 254 4464 906 Electrolytic 100uF/6.3V CE67C0J101M
C673,674 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C679-682 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C684,685 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
for E2,E1,E1C,EUT
C686 254 4465 918 Electrolytic 47uF/16V CE67C1C470M
for E2,E1,E1C,EUT
C687,688 254 4464 906 Electrolytic 100uF/6.3V CE67C0J101M
C689 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
for E2,E1,E1C,EUT
C690-692 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
for E2,E1,E1C,EUT
C693,694 254 4464 906 Electrolytic 100uF/6.3V CE67C0J101M
C695 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
for E2,E1,E1C,EUT
C696 254 4571 938 Electrolytic 0.47uF/50V CE67C1HR47M (MV-B)
for E2,E1,E1C,EUT
C697 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
for E2,E1,E1C,EUT
C701,702 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C705 254 4571 938 Electrolytic 0.47uF/50V CE67C1HR47M (MV-B)
for E2,E1,E1C,EUT
C706 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
for E2,E1,E1C,EUT
C707 254 4572 908 Electrolytic 10uF/16V CE67C1C100M (MV-B)
for E2,E1,E1C,EUT
C708 254 4571 912 Electrolytic 1uF/50V CE67C1H010M (MV-B)
for E2,E1,E1C,EUT
C711 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
for E2,E1,E1C,EUT
C712 254 4571 912 Electrolytic 1uF/50V CE67C1H010M (MV-B)
for E2,E1,E1C,EUT
C715 254 4571 938 Electrolytic 0.47uF/50V CE67C1HR47M (MV-B)
for E2,E1,E1C,EUT
C716 254 4571 912 Electrolytic 1uF/50V CE67C1H010M (MV-B)
for E2,E1,E1C,EUT
C725 254 4465 918 Electrolytic 47uF/16V CE67C1C470M
for E2,E1,E1C,EUT
C726 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
for E2,E1,E1C,EUT
C727 254 4571 938 Electrolytic 0.47uF/50V CE67C1HR47M (MV-B)
for E2,E1,E1C,EUT
C728 257 3006 911 Metallized chip 0.1uF/16V CF73=1C104J (ECHUB5)
C731 257 4010 906 Electrolytic 100uF/16V CE67C1C101M
C732 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C733,734 257 0503 941 Ceramic chip 12pF/50V CC73CH1H120J
C735,736 257 0504 908 Ceramic chip 22pF/50V CC73CH1H220J
C739,740 254 4464 906 Electrolytic 100uF/6.3V CE67C0J101M
C741,742 257 0503 941 Ceramic chip 12pF/50V CC73CH1H120J
C743 254 4571 909 Electrolytic 0.22uF/50V
CE67C1HR22M (MV-B)
C744 257 3011 948 Metallized chip 2200pF/50V CF73=1H222J (ECHUB5)
C747 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C748 254 4571 925 Electrolytic 2.2uF/50V CE67C1H2R2M (MV-B)
C752,753 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C754,755 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C756 257 3006 911 Metallized chip 0.1uF/16V CF73=1C104J (ECHUB5)
C760,761 257 3006 911 Metallized chip 0.1uF/16V CF73=1C104J (ECHUB5)
C767 257 3006 911 Metallized chip 0.1uF/16V CF73=1C104J (ECHUB5)
C768 254 4571 925 Electrolytic 2.2uF/50V CE67C1H2R2M (MV-B)
C770 257 3014 987 Metallized chip 0.022uF/16V CF73=1C223J (ECHUB5)
C774,775 257 3006 911 Metallized chip 0.1uF/16V CF73=1C104J (ECHUB5)
C776 257 0503 941 Ceramic chip 12pF/50V CC73CH1H120J
C777 257 3006 911 Metallized chip 0.1uF/16V CF73=1C104J (ECHUB5)
C778 257 0504 908 Ceramic chip 22pF/50V CC73CH1H220J
C780 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
C781 257 4010 906 Electrolytic 100uF/16V CE67C1C101M
C782-785 254 4464 951 Electrolytic 22uF/6.3V CE67C0J220M (MV-B)
C791 254 4464 919 Electrolytic 470uF/6.3V CE67C0J471M
C792 254 4464 906 Electrolytic 100uF/6.3V CE67C0J101M
