15
AVR-1910/1620/1610/790/590
8. TRANS MAIN
(1) Loose the style pin.
(2) Loose the Cord holder, then disconnect the connector wire.
(3) Remove the screws.
Proceeding : CABINET TOP TRANS MAIN
Direction of photograph: D
Style pin : Loose
CP1002
CP1004
CP1307
CP1300
Cord holder : Loose
