Denon AVR-989 Service Manual

142
AVR-2809CI / AVR-2809 / AVR-989 / AVC-2809
5 nsp POWER AMP UNIT EU, 989EU, EC 1
5 nsp POWER AMP UNIT E2, E1C 1
5 nsp POWER AMP UNIT JP 1
5-1 P.AMP UNIT
5-10 REG CONNECT UNIT
5-11 P.AMP HOLDER UNIT
6 nsp MAIN CPU UNIT EU, EC 1
6 nsp MAIN CPU UNIT 989EU 1
6 nsp MAIN CPU UNIT E2 1
6 nsp MAIN CPU UNIT E1C 1
6 nsp MAIN CPU UNIT JP 1
6-1 MAIN CPU UNIT
6-2 POWER UNIT
6-3 PRIM/CPU SUPPLY UNIT
6-4 UCON JUNCTION UNIT
6-5 E2 OUTLET UNIT E2
6-6 TUNER UNIT E1C,JP
11 402410041006D FRONT PANEL EU, EC : BK model 1
11 402410044005D FRONT PANEL 989EU : BK model 1
11 402410041013D FRONT PANEL E2 : BK model 1
11 402410041020D FRONT PANEL E2 : SP model 1
11 402410041037D FRONT PANEL E1C, JP : SP model 1
12 00D1310169038 DENON BADGE BK model 1
12 00D1310169041 DENON BADGE SP model 1
13 00D1431232006 LENS 3
14 424510010001D KNOB GUIDE (A) 989EU 1
15 424510011004D KNOB GUIDE (B) 989EU 1
16 415410002007D DOOR EU, 989EU, EC : BK model 1
16 415410002014D DOOR E2 : BK model 1
16 415410002021D DOOR E2 : SP model 1
16 415410002045D DOOR E1C : SP model 1
16 415410002038D DOOR JP : SP model 1
17 00D4010195202 HINGE (L) BK model 1
17 00D4010195231 HINGE (L) SP model 1
18 00D4010196201 HINGE (R) BK model 1
18 00D4010196230 HINGE (R) SP model 1
19 424510006002D KNOB RING(M) EU, EC, E2 : BK model 1
19 424510008008D KNOB RING(M) 989EU : BK model 1
19 424510006019D KNOB RING(M) E2, E1C, JP : SP model 1
20 00D1140203009 KNOB RING(F) EU, EC, E2 : BK model 1
20 424510007005D KNOB RING(F) 989EU : BK model 1
20 00D1140203025 KNOB RING(F) E2, E1C, JP : SP model 1
21 412010017004D KNOB(M) ASSY BK model 1
21 412010017011D KNOB(M) ASSY SP model 1
22 412010016001D KNOB(F) ASSY BK model 1
22 412010016018D KNOB(F) ASSY SP model 1
23 443510009002D INNER PANEL EU, EC : BK model 1
23 443510010002D INNER PANEL 989EU : BK model 1
23 443510009019D INNER PANEL E2 : BK model 1
23 443510009026D INNER PANEL E2, E1C, JP : SP model 1
24 422510017006D DOOR SHEET EU, EC, E2 : BK model 1
24 422510017020D DOOR SHEET 989EU : BK model 1
24 422510017013D DOOR SHEET SP model 1
25 nsp RUBBER SHEET DOOR CLOSE 2
Ref. No. Part No. Part Name Remarks Q'ty New
