143
AVR-2809CI / AVR-2809 / AVR-989 / AVC-2809
26 nsp RUBBER SHEET DOOR OPEN 2
27 416510011003D WINDOW 1
28 00D1131996202 CURSOR KNOB BK model 1
28 00D1131996231 CURSOR KNOB SP model 1
29 00D1131995041 ENTER KNOB BK model 1
29 00D1131995038 ENTER KNOB SP model 1
30 00D1431255009 LENS (POWER) 1
31 00D1131992109 P.KNOB ASSY(SUB) BK model 1
31 00D1131992138 P.KNOB ASSY(SUB) SP model 1
32 00D1131994107 P.KNOB ASSY(MAIN) BK model 1
32 00D1131994149 P.KNOB ASSY(MAIN) SP model 1
33 00D4210763010 GEAR DAMPER 1
34 nsp DOOR STOPPER 1
35 nsp FRONT BRACKET 1
36 00DGEN8688 TOP COVER SUB ASSY BK model 1
36 8S4031000700D TOP COVER SUB ASSY SP model 1
37 nsp MAIN CHASSIS 1
38 nsp BRACKET 2
39 00D1040334007 FOOT 4
40 00D4610385001 RUBBER PAD 4
41 nsp SUPPORT BRACKET 1
42 nsp SCREW COVER (BOTTOM) 1
z 43 00D2336616001 POWER TRANS (E3) EU, 989EU, EC 1
z 43 00D2336585006 MAIN TRANS(28CIE2) E2 1
z 43 00D2336587004 MAIN TRANS(28CIE1C) E1C 1
z 43 00D2330729004 MAIN TRANS(28CIJP) JP 1
44 406310008040D BACK PANEL EU, EC 1
44 406310008088D BACK PANEL 989EU 1
44 406310008057D BACK PANEL E2 1
44 406310008071D BACK PANEL E1C 1
44 406310008064D BACK PANEL JP 1
45 00D2160124002 AM FM TUNER(E3) EU, 989EU, EC 1
45 00D2160125001 AM FM TUNER(E2) E2 1
46 00D2051116006 TERMINAL ASS 1
47 nsp SCREW COVER 1
48 nsp RADIATOR 1
49 00D2780020007 2SB1647/2SD2560(P/Y)-LF 7
49-1 - 2SB1647
49-2 - 2SD2560
50 nsp RADIATOR BRACKET (L) 1
51 nsp RADIATOR BRACKET (R) 1
52 - H/P PLATE Cut INN.PANEL 1
53 - D/S PLATE Cut INN.PANEL 1
54 nsp CARD SPACER (L=8) 3
55 nsp CARD SPACER(L=10) 4
56 nsp LOCKING CARD SPACER 1
57 nsp P.W.B.HOLDER (H=10) 1
58 nsp FFC HOLDER 1
★ 61
nsp RUBBER SHEET 1
★ 62
nsp SHIELD PLATE 1
★ 63
nsp SPACER 2
★ 64
00D4141058014 SAFETY COVER E2 : BK model 1
★ 65
00D4141058001 SAFETY COVER E2, E1C : SP model 1
★ 66
00D4490139105 COVER HOLDER E2 : BK model 6
★ 67
00D4490139118 COVER HOLDER E2, E1C : SP model 6
Ref. No. Part No. Part Name Remarks Q'ty New
