Denon AVR-989 Service Manual

144
AVR-2809CI / AVR-2809 / AVR-989 / AVC-2809
★ 68
nsp LICENSE SUB ASSY EU, 989EU, EC 1
★ 69
nsp LICENSE SUB ASSY E2, E1C 1
★ 70
nsp LICENSE SUB ASSY JP 1
★ 71
nsp SERIAL NO. SHEET 1
★ 72
nsp PUSH RIVET 1
★ 73
nsp SP RIVET E2, E1C 18
★ 74
nsp FUSE CAUTION LABEL EU, 989EU, EC 1
★ 75
nsp CCC LABEL E1C 1
★ 76
nsp CROHS LABEL E1C 1
★ 77
nsp NOTICE SHEET JP 1
Wires
★ 81
606050033007D FFC 15P 170mm 1.25mm 1
★ 82
606050031001D FFC 27P 230mm 1mm 1
★ 83
606050032004D FFC 27P 425mm 1mm 1
★ 84
nsp 10P 350mm PH-PH EU, 989EU, EC 1
Screws
201 00D4770064107 FIXING SCREW
202 nsp 3X8 CBTS (S)-Z
203 nsp 4X8 TP SCREW
204 nsp 3X5 CBS
205 nsp 3X6 CBTS(S)-B
207 nsp 3X8 CBTS (P)-Z
208 nsp 3X8 CFTS (P)-Z
210 nsp 3X8 CUP SCREW
211 nsp 3X10 CBTS(B)-Z
212 0RD4738064000 4X8 CBTS(B)-B-3P
213 nsp 3X16 CPTS(B) SW W
Ref. No. Part No. Part Name Remarks Q'ty New
s
