Denon AVR-S700W User Manual

Adjusting the volume of each channel
to match the input source (Ch Level
Adjust)
The volume of each channel can be changed while listening to music. You
can set this for each input source.
1
Press OPTION.
The option menu screen is displayed.
2
Use ui to select “Ch Level Adjust”, then press ENTER.
The channel level adjust screen is displayed.
3
Use ui to select the channel that you wish to adjust.
4
Use o p to adjust the volume, then press ENTER.
–12.0 dB – +12.0 dB (Default : 0 dB)
0
Select “Reset” and press ENTER if you want to restore the adjustment values of
the various channels to “0 dB” (default).
0
Headphone volume can be adjusted when a headphone is connected.
0
“Ch Level Adjust” settings are stored for each input source.
0
You can only set this for speakers that output audio. In addition, you cannot set
this when in the menu “HDMI Audio Out” (v
p. 148) is set to “TV”.
Contents Connections Playback Settings Tips Appendix
107
Front panel Display Rear panel Remote Index

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
