Denon AVR-S700W User Manual

Audyssey
Set Audyssey MultEQ
®
, Audyssey Dynamic EQ
®
and Audyssey Dynamic
Volume
®
. These can be selected after Audyssey
®
Setup has been
performed.
For additional information on Audyssey technology, please see
“Explanation of terms” (v
p. 223).
0
“MultEQ
®
”, “Dynamic EQ” and “Dynamic Volume” settings are stored for each
input source.
0
When the sound mode is in the “Direct” mode, “MultEQ
®
”, “Dynamic EQ” and
“Dynamic Volume” settings cannot be configured.
o
MultEQ
®
MultEQ
®
compensates for both time and frequency characteristics of
the listening area based on “Audyssey
®
Setup” measurement results.
Selection is done from three types of compensation curves. We
recommend the “Reference” setting.
Reference
(Default):
Selects the default calibrated setting with
a slight roll off at high frequencies, which
is optimized for movies.
L/R Bypass:
Selects the reference setting, but
bypasses MultEQ
®
on the front left and
right speakers.
Flat:
Selects the calibrated setting which is
optimized for small rooms where your
listening position is closer to the
speakers.
Off :
Do not use “MultEQ
®
”.
When using headphones, “MultEQ
®
” is automatically set to “Off”.
Contents Connections Playback Settings Tips Appendix
144
Front panel Display Rear panel Remote Index

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
