Denon AVR-S700W User Manual

ZONE2 Setup
Configure the settings for audio playback on ZONE2.
Values set for “Volume Limit” and “Pow.On Volume” are displayed according to the
setting specified for the volume “Scale” (v p. 143).
o
Volume Level
Set the volume output level.
Variable
(Default) :
Volume can be adjusted.
1 – 98
(–79.5 dB – 18.0 dB):
Volume is fixed at the desired level. The
volume cannot be adjusting using the remote
control unit.
o
Volume Limit
Make a setting for maximum volume.
60 (-20 dB) / 70 (-10 dB) / 80 (0 dB)
(Default : 70 (-10 dB))
Off: Do not set a maximum volume.
This can be set when “Volume Level” is set to “Variable”. (v p. 182)
o
Pow.On Volume
Define the volume setting that is active when the power is turned on.
Last
(Default) :
Use the memorized setting from the last
session.
Mute: Always use the muting on condition.
1 – 98
(–79.5 dB – 18.0 dB):
The volume is adjusted to the set level.
This can be set when “Volume Level” is set to “Variable”. (v p. 182)
Contents Connections Playback Settings Tips Appendix
182
Front panel Display Rear panel Remote Index

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
