Denon AVR-S700W User Manual

Manual Setup
Perform when setting the speakers manually or when changing settings
made in Audyssey
®
Setup.
0
If you change the speaker settings after performing Audyssey
®
Setup,
you will no longer be able to select Audyssey MultEQ
®
, Audyssey
Dynamic EQ
®
and, Audyssey Dynamic Volume
®
. (v p. 144 – 146)
0
“Manual Setup” can be used without changing the settings. Please set if
necessary.
Amp Assign
Select power amplifier usage method to match your speaker system.
See “Speaker configuration andAmp Assignsettings” (v
p. 31) regarding
the speaker configuration and connection.
o
Assign Mode
Select how to use the power amp.
Surround Back:
Setting for 7.1-channel playback using
surround back speakers.
ZONE2
(Default):
Setting to assign the unit’s built-in power
amplifier for ZONE2 and output the audio
in stereo.
Front Height:
Setting for 7.1-channel playback using
front height speakers.
Contents Connections Playback Settings Tips Appendix
167
Front panel Display Rear panel Remote Index

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
