Denon AVR-S700W - Page 19

.
IMPEDANCE : 4㹼16Ȑ
SPEAKERS
ASSIGNABLE
ANTENNA
1
CBL/SAT 4 Blu-ray 5 GAME
MEDIA
PLAYER
3
DVD/
Blu-ray
2
(4K)(4K)
HDMI
(
ASSIGNABLE
)
IN
NETWORK
CLASS 2 WIRING
PRE OUT
1
2
SUBWOOFER
CBL/SAT
MEDIA
PLAYER
TV AUDIO
12
COAXIAL OPTICAL
IN
DIGITAL AUDIO
(
ASSIGNABLE
)
75Ȑ
FMAM
FRONT FRONT CENTER SURROUND SURROUND BACK SURROUND BACK SURROUND
MONITOR
ARC
HDMI
OUT
1 CBL/SAT
MEDIA
PLAYER
2
VIDEO
OUT
MONITOR
VIDEO
IN
(
ASSIGNABLE
)
AUDIO
(
ASSIGNABLE
)
IN
MEDIA
PLAYER
12
CBL/SAT
ytuiqqrew
A
Rod antennas for Bluetooth/wireless LAN
Stand this antenna upright when connecting to a network via wireless
LAN, or when connecting to a handheld device via Bluetooth.
(v p. 49)
.
90°
320°
320°
90°
The antenna clip can be removed from the rear panel.
A
Rotate the antenna clip 90 degrees to the left.
B
Pull the antenna clip out towards yourself.
0
The antenna clip is needed when transporting this unit. Keep it in a safe place.
0
Attach the antenna clip by following the steps for removing it in reverse.
B
Analog audio connectors (AUDIO)
Used to connect devices equipped with analog audio connectors.
(v
p. 41, 42)
C
PRE OUT connectors
Used to connect a subwoofer with a built-in amplifier. (v p. 29,
128)
D
Digital audio connectors (DIGITAL AUDIO)
Used to connect devices equipped with digital audio connectors.
(v
p. 38, 42)
E
NETWORK connector
Used to connect to a LAN cable when connecting to a wired LAN
network. (v
p. 48)
F
HDMI connectors
Used to connect devices equipped with HDMI connectors.
(v
p. 37, 38, 41, 42)
G
Video connectors (VIDEO)
Used to connect devices equipped with video connectors.
(v
p. 41, 42)
H
Power cord (v
p. 50)
