Denon AVR-S700W User Manual

5
n Connect to the network.
Wired LAN
When connecting cables (wired connection), connect a LAN
cable between your receiver and your network router.
ANTENNA
1
CBL/SAT 4 Blu-ray 5 GAME
MEDIA
PLAYER
3
DVD/
Blu-ray
2
(4K)(4K)
HDMI
(
ASSIGNABLE
)
IN
PRE OUT
1
2
SUBWOOFER
CBL/SAT
MEDIA
PLAYER
TV AUDIO
12
COAXIAL OPTICAL
IN
DIGITAL AUDIO
(
ASSIGNABLE
)
75Ȑ
FMAM
1 CBL/SAT
MEDIA
PLAYER
2
VIDEO
OUT
MONITOR
VIDEO
IN
(
ASSIGNABLE
)
AUDIO
(
ASSIGNABLE
)
IN
MEDIA
PLAYER
12
CBL/SAT
IMPEDANCE : 4㹼16Ȑ
SPEAKERS
ASSIGNABLE
CLASS 2 WIRING
FRONT FRONT CENTER SURROUNDSURROUND SURROUND BACK SURROUND BACK
MONITOR
ARC
HDMI
OUT
SURROUNDSURROUND
NETWORK
Internet
Modem
Router
To WAN side
To LAN port
Wireless LAN
When using a wireless connection (Wi-Fi), rotate the
antennas upword.
ANTENNA
1
CBL/SAT 4 Blu-ray 5 GAME
MEDIA
PLAYER
3
DVD/
Blu-ray
2
(4K)(4K)
HDMI
(
ASSIGNABLE
)
IN
PRE OUT
1
2
SUBWOOFER
CBL/SAT
MEDIA
PLAYER
TV AUDIO
12
COAXIAL OPTICAL
IN
DIGITAL AUDIO
(
ASSIGNABLE
)
75Ȑ
FMAM
1 CBL/SAT
MEDIA
PLAYER
2
VIDEO
OUT
MONITOR
VIDEO
IN
(
ASSIGNABLE
)
AUDIO
(
ASSIGNABLE
)
IN
MEDIA
PLAYER
12
CBL/SAT
IMPEDANCE : 4㹼16Ȑ
SPEAKERS
ASSIGNABLE
CLASS 2 WIRING
FRONT FRONT CENTER SURROUNDSURROUND SURROUND BACK SURROUND BACK
MONITOR
ARC
HDMI
OUT
SURROUNDSURROUND
NETWORK
Router with
access point
To WAN side
Internet
Modem

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
