Denon AVR-S730H

POWER DIAGRAM
AVRS730H/X1400H VCC DIAGRAM
MAIN+B
MAIN-B
AC CORD
RELAY
!
!
!
MAIN TRANS
S2 TOTAL : 602.63mA
!
S4(FILAMENT)
S3(FL+Vdisp)
S2(+12V,-12V)
S1(AMP+B,-B)
KIA7812BPI
KIA7912PI
FILAMENT AC
A+12V
DA+5V
A-12V
Vdisp(+37V)
KIA7805BPI
+5.2V
MAIN PWR ON
TUNER+5V
FILAMENT AC
V-5V
V+5V
MM1Z7V5
SELETOR IC,VOLUME IC
(NJU72750AV,NJU72343V)
MCU_3V3/MICOM
SWM3.3V/LEVEL_CHG
DA3.3V/DIR,DSP
TPS563200(+1.0V)
TPS563200(+3.3V)
NJM2845DL133
CEC5V
CEC3V3/HDMI
DA1.0V/DSP
D1V8H/HDMI
D5V/VBUS
DV5V/HDMI
(ADV7623)
(AD8195,MN864787,MN
864788)
(R5F5631FDD
FB,VFD,MC74HC4094x2)
(AD8195)
(PCM9211PTR,AK4458VN)
(NJM8080,SPK/H-P/HI-LOW RELAY)
(CS49844A)
(NJM2595)
36mA
281mA
122mA
22mA
50mA
68mA
163mA
482.02mA
1029mA
982mA
1503.5mA
260.5mA
* TOTAL (5V): 1050.403mA
TPS563200(+1.8V)
1000mA
2010.18mA
260.5mA
20.4mA
(NJM2595)
MCU+5V (CVDBLBJEGJ204L)FRONT LED
30mA
1022.0mA
SMPS Total Current : About 4248.829mA
BU33TD3WG
45mA
DA+3.3V (PCM5100)
MM1Z5V1
MM1Z5V1
MM1Z7V5
(SN74CBT3251PWR)SWM5V
0.003mA
406.83mA
INPUT CURRENT (Ref Volage:5.2V)
NET3.3V/NETWORK
(IPOD AUTH,SN74LVC244APWRx4)
160.16mA
PLD1.8V/PLD
(5M570ZF256C5N)
(CS49844A,M12L64164A-5TG2Y,5M570ZF256C5N,TC74VHCU04,MX25L6406EM2I-12G,PCM9211,AK4458VN)
MM1Z6V8
MM1Z6V8
ZONE VOLUME IC
(BD3812F)
ZONE VOLUME IC
(BD3812F)
AVRX1300W E3 ONLY
40mA
HI+B
LOW-B
3000mA
CEC1V1
(MN864787,MN864788)
34mA
*DC-DC Effieciency:85%
260.526mA
1467.04mA
332.5mA
(5.2V)
(5.2V)
(5.2V)
(5.2V)
HI-B
LOW+B
DV3V3
(ADV7623,MX25L3206E/MX25L6406EM2I-12G)
339mA
TPS563200(+1.1V)
729.81mA
(5.2V)
LEGO5V
(LEGO)
636mA
(NJM2115MTE1x2,AK5358BET)
SELETOR IC,VOLUME IC
(NJU72750AV,NJU72343V)
1
3
4
2
S
G
D
12
3 4
40
