Denon AVR-S730H Service Manual

ZONE2 ch
LINE IN 0dB
(200m V)
-10dB
-20dB
-40dB
-30dB
+10dB
+20dB
AVRS730H/X1400H LEVEL DIAG RAM
H/P OU T
SPK O UT
FRO NT
ZO NE2
BD3812F
-50dB
0dB (200m Vrm s)
-10dB
-20dB
-40dB
-30dB
+10dB
+20dB
-50dB
+30dB
+29dB
4.27Vrms /8ohm
277m Vrm s/33ohm
SPK O UT
G A IN
ADJ.
PRE OUT 150m Vrm s
H/P OU T
PO W ERAM P G AIN
ANALO G
NJM 8080 M AX.O U T P UT 7.78Vrm s
-18dB
+15dB
ZO NE2 O U T
LINE IN
NJU72340A
M IC IN
NJU72343V
VO L U ME IC : NJU 72343 N O N CLIP M AX SIG NA L LEVEL 4.2Vrm s
36
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-S730H Specifications

General

Channels	7.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	110W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	165W
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
DTS Virtual:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
4K Ultra HD Pass-through	Yes
HDR Support	Yes (HDR10, Dolby Vision, HLG)
Auto Speaker Calibration	Audyssey MultEQ
AirPlay	Yes (AirPlay 2)
Internet Radio	Yes
Phono Input	No
Ethernet Port	Yes
Power Output per Channel	75W (8 ohm, 20Hz-20kHz, 0.08% 2ch Drive)
USB Input	1 (Front)
