Denon AVR-S730H Service Manual

2. PANEL / REMOTE LOCK Selection Mode
2.1. Actions
Switch the PANEL LOCK and REMOTE LOCK modes between on and off.
2.2. Starting up
While holding down buttons "
TUNER PRESET CH+
" and "ZONE2 SOURCE" simultaneously, press the
power button to turn on the power.
Select the desired mode using the "
TUNER PRESET CH+/-
" button, then press the "
STATUS
" button to
conrm.
2.3. Displaying and Selecting Each Mode
The information shown on the display switches each time the "
TUNER PRESET CH+
" button is
pressed.
Press the "
STATUS
" button to set the currently displayed mode and restart the device.
The setting with "
*
" is selected for each mode.
q
FP/VOL LOCK*On
The buttons on the unit and the master volume knob does not function.
w
FP LOCK On
The buttons on the unit does not function.
e
FP LOCK Off
The PANEL LOCK mode is turned off.
r
RC LOCK On
The device cannot be operated by the remote control.
t
RC LOCK *Off
The REMOTE LOCK mode is turned off.
112
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-S730H Specifications

General

Channels	7.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	110W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	165W
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
DTS Virtual:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
4K Ultra HD Pass-through	Yes
HDR Support	Yes (HDR10, Dolby Vision, HLG)
Auto Speaker Calibration	Audyssey MultEQ
AirPlay	Yes (AirPlay 2)
Internet Radio	Yes
Phono Input	No
Ethernet Port	Yes
Power Output per Channel	75W (8 ohm, 20Hz-20kHz, 0.08% 2ch Drive)
USB Input	1 (Front)
