Denon AVR-S770H User Manual

Setting items Detailed items Description Page
Inputs
Input Assign Changes input connector assignment and the audio input mode. 174
Source Rename Changes the display name for input source. 177
Hide Sources Selects source inputs to hide on the user interface and front panel displays. 177
Source Level Adjusts the input level for the current source. 177
Speakers
Audyssey
®
Setup
The acoustic characteristics of the connected speakers and listening room are
measured and the optimum settings are made automatically.
178
Manual Setup
Sets up the speakers manually or changes Audyssey
®
Setup settings.
188
Network
Information Displays network information. 196
Connection Configures the network connection. 196
Settings Configures the network settings (DHCP and IP address). 199
Network Control Enables network communication in standby power mode. 200
Friendly Name Edits the name of this unit that is displayed on the network. 201
Diagnostics Tests the network connection. 201
AirPlay Settings for Apple AirPlay. 202
Spotify Connect Toggles access to Spotify Connect. 203
Wi-Fi and Bluetooth Toggles power to the Wi-Fi and Bluetooth radios. 203
Contents Connections Playback Settings Tips Appendix
148
Front panel Display Rear panel Remote Index

Denon AVR-S770H Specifications

General

Channels	7.2
HDMI Inputs	6
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
Input Sensitivity/Impedance	200mV/47k ohms
Signal-to-Noise Ratio	98 dB (IHF-A weighted, Direct mode)
Ethernet Port	Yes
HDR Support	HDR10+, Dolby Vision, HLG
Frequency Response	10Hz-100kHz
USB Port	Yes
HDMI Outputs	1
