Denon AVR-S770H User Manual

Speakers
The acoustic characteristics of the connected speakers and listening room are measured and the optimum settings are made automatically. This is called
“Audyssey
®
Setup”.
You do not have to perform Audyssey
®
Setup when you have already performed “Speaker Calibration” in “Setup Assistant”.
To set up the speakers manually, use “Manual Setup” on the menu. (v p. 188)
Audyssey
®
Setup
To perform measurement, place the Sound calibration microphone in
multiple locations all around the listening area. For best results, we
recommend you measure in six or more positions, as shown in the
illustration (up to eight positions).
When measuring the second and subsequent positions, install the Sound
calibration microphone within 60 cm of the first measurement position
(main listening position).
0
If you perform Audyssey
®
Setup, Audyssey MultEQ
®
, Audyssey Dynamic EQ
®
and Audyssey Dynamic Volume
®
functions are enabled. (v p. 161)
FL SW C FR
SRSL
Surround speaker (R)
Surround speaker (L)
Subwoofer
Center speaker
Front speaker (R)
Front speaker (L)
( :Measuring positions)
FL
FR
C
SW
SL
SR
Listening position
Contents Connections Playback Settings Tips Appendix
178
Front panel Display Rear panel Remote Index

Denon AVR-S770H Specifications

General

Channels	7.2
HDMI Inputs	6
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
Input Sensitivity/Impedance	200mV/47k ohms
Signal-to-Noise Ratio	98 dB (IHF-A weighted, Direct mode)
Ethernet Port	Yes
HDR Support	HDR10+, Dolby Vision, HLG
Frequency Response	10Hz-100kHz
USB Port	Yes
HDMI Outputs	1
