Denon AVR-S770H User Manual

Quick Select
Sets the “Quick Select” parameters and display name.
o
Name
Change the Name that appears on the TV screen to one you prefer.
0
Up to 16 characters can be input.
o
Input Source/Master Volume/Sound Mode/
Channel Level/Audyssey Parameters/Restorer/
Playback Content/Speaker Preset/All Zone
Stereo/TV Audio Sharing
Enabled
(Default):
The current settings are registered when
Quick Select is registered. In addition,
when Quick Select is called up, the
content of the registered settings is called
up.
Disabled:
Settings are not registered when Quick
Select is registered. In addition, when
Quick Select is called up, the content of
the registered settings is not called up.
0
“Quick Select” can be set for each Quick Select.
0
When “Input Source” is “Disabled”, Video Select information is not registered/
called up either.
Front Display
Makes settings related to the display on this unit.
o
Brightness
Adjust the display brightness of this unit.
Bright
(Default):
Normal display brightness.
Dim: Reduced display brightness.
Dark: Very low display brightness.
Off: Turns the display off.
0
You can also adjust the display by pressing DIMMER on the main unit.
Contents Connections Playback Settings Tips Appendix
212
Front panel Display Rear panel Remote Index

Denon AVR-S770H Specifications

General

Channels	7.2
HDMI Inputs	6
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
Input Sensitivity/Impedance	200mV/47k ohms
Signal-to-Noise Ratio	98 dB (IHF-A weighted, Direct mode)
Ethernet Port	Yes
HDR Support	HDR10+, Dolby Vision, HLG
Frequency Response	10Hz-100kHz
USB Port	Yes
HDMI Outputs	1
