Denon AVR-S770H User Manual

3
Connect the Sound calibration microphone to the
SETUP MIC jack of this unit.
When the Sound calibration microphone is
connected, the following screen is displayed.
Speaker Layout
Dolby Speaker Setup
Start
Audyssey Setup
Your AVR can automatically measure the acoustics of your
room then optimize your speakers using the included
microphone and microphone stand.
Set the following items if necessary.
Speaker Preset 1
4
Select “Start”, then press ENTER.
Audyssey
®
Setup can also make the following settings.
0
Speaker Layout
Set the Speaker Layout to suit your speaker environment.
0
Dolby Speaker Setup
Set the distance between the Dolby Atmos Enabled speaker and
the ceiling.
This can be set when using the Front Dolby Atmos Enabled
speakers or Surround Dolby Atmos Enabled speakers.
5
Follow the instructions on the screen display and press
“Next” to proceed further.
Contents Connections Playback Settings Tips Appendix
181
Front panel Display Rear panel Remote Index

Denon AVR-S770H Specifications

General

Channels	7.2
HDMI Inputs	6
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
Input Sensitivity/Impedance	200mV/47k ohms
Signal-to-Noise Ratio	98 dB (IHF-A weighted, Direct mode)
Ethernet Port	Yes
HDR Support	HDR10+, Dolby Vision, HLG
Frequency Response	10Hz-100kHz
USB Port	Yes
HDMI Outputs	1
