Denon AVR-S770H User Manual

8
Move the Sound calibration microphone to position 2,
select “Continue”, then press ENTER.
The measurement of the second position starts.
Measurements can be made in up to six positions.
2
Audyssey Setup
•••••••••• Ear Height
Back
Place the microphone at the ear level of the listener seated
at the 2nd listening position, which should be no more
than 60 cm away from the 1st listening position, then
select "Continue ...
Continue
n
Stopping Audyssey
®
Setup
A
Press BACK to display the popup screen.
B
Press cursor Left to select “Yes”, then press ENTER.
9
Repeat step 8, measuring positions 3 to 6.
0
To skip measuring the fourth and subsequent listening position, press
cursor Left to select “Complete” and press ENTER to proceed to step 11.
10
Select “Continue”, then press ENTER.
Audyssey Setup
Repeat Last Test
Continue
Measurements complete.
Select "Continue" to analyze the data...
Start the analysis and storage of the measurement results.
0
Analysis takes several minutes to complete.
The more speakers and measurement positions that there are,
the more time it takes to perform the analysis.
NOTE
0
When the measurement results are being saved, make sure the power is
not turned off.
Contents Connections Playback Settings Tips Appendix
183
Front panel Display Rear panel Remote Index

Denon AVR-S770H Specifications

General

Channels	7.2
HDMI Inputs	6
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
Input Sensitivity/Impedance	200mV/47k ohms
Signal-to-Noise Ratio	98 dB (IHF-A weighted, Direct mode)
Ethernet Port	Yes
HDR Support	HDR10+, Dolby Vision, HLG
Frequency Response	10Hz-100kHz
USB Port	Yes
HDMI Outputs	1
