Denon AVR-S970H - Example layout when using front Dolby Atmos Enabled speakers

o
Example layout when using front Dolby Atmos
Enabled speakers
This 7.1-channel surround system is the same as a basic 5.1-channel
system but with front Dolby Atmos Enabled speakers.
C
SWFL FR
SL SR
FDL FDR
0
Set “Assign Mode” to “Front Dolby” in the menu. (v p. 187)
FDR FDL
SW FLFR C SR SL
