Denon AVR-S970H - Example layout when using surround Dolby Atmos Enabled speakers

o
Example layout when using surround Dolby
Atmos Enabled speakers
This 7.1-channel surround system is the same as a basic 5.1-channel
system but with surround Dolby Atmos Enabled speakers.
C
FL FR
SW
SL SR
SDL SDR
0
Set “Assign Mode” to “Surround Dolby” in the menu. (v p. 187)
SDR SDL
SW FLFR C SR SL
