Denon AVR-X1100W User Manual

6
Follow the instructions on the screen display and press
“Next” to proceed further.
7
When the following screen is displayed, select “Begin
Test” and then press ENTER.
Start the measurement of the first position.
.
Place the microphone at ear level at the main listening position.
Make sure you are always 50cm from the back wall of
your room for each test.
Ear Height
Audyssey Setup
NextBack
0
Measurement requires several minutes.
NOTE
If “Caution!” is displayed on TV screen:
Go to “Error messages” (v p. 161). Check any related items, and perform
the necessary procedures.
8
When the detected speaker is displayed, select “Next”
and then press ENTER.
.
Audyssey Setup
Speaker Detection
NextRepeat Last Test
Front
Center
Subwoofer
Surround
S. Back
Yes
Yes
Yes
Yes
No
Contents Connections Playback Settings Tips Appendix
157
Front panel Display Rear panel Remote Index

Denon AVR-X1100W Specifications

General

Receiver type	Surround
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
Supported radio bands	AM, FM
Optical drive included	No
Display	VFL
Product color	Black
Audio decoders	Dolby Digital 5.1, Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Plus, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8600 g
