FM/AM antenna terminals (ANTENNA)
Used to connect FM antennas and AM loop antennas. (v p. 48)
J
Speaker terminals (SPEAKERS)
Used to connect speakers. (v
p. 28)
NOTE
Do not touch the inner pins of the connectors on the rear panel. Electrostatic
discharge may cause permanent damage to the unit.
