Denon AVR-X1400H Troubleshooting Guide

Introduction
HDMI Diagnostics and Troubleshooting
4
Compatible Models
4
How to operate
How to operate
5
Starting HDMI DIAGNOSTICS Mode
5
HDMI DIAGNOSTICS Menu
6
To exit HDMI DIAGNOSTICS Mode
7
Initialization
8
Reset option in HDMI DIAGNOSTICS mode
8
Factory Reset mode
8
Customer Support
9
For US & Canada
9
For Europe
9
For the other region
9
Cable Test
Procedure
10
Test Item & Test Result
11
Limit mode
Limit Mode Menu
12
Source Selection
12
Setting
13
Max Resolution
13
HDCP2.2 / HDR / Deep Color / Dolby Vision / DTS:X / Dolby Atmos / PCM 2ch only
14
Reset
14
Procedure (Max Resolution)
15
Tips for Limit Mode Setup
17
2 Max Resolution
17
3 HDCP 2.2
17
4 HDR
17
5 Deep Color
17
6 Dolby Vision
17
7 DTS:X
18
8 Dolby Atmos
18
9 PCM 2ch only
18
Introduction How to operate Cable Test Limit mode Log & EDID Troubleshooting
2

Denon AVR-X1400H Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Pre-out channels	2 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Audio formats supported	ALAC, DSD, FLAC, MP3, WAV
Display	VFL
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround
Volume control	Rotary
Center speaker impedance	16 Ω
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, iHeartRadio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
Supported video modes	720i, 720p, 960p, 1080i, 1080p, 2160p
Supported graphics resolutions	3840 x 2160
Certification	CE, EAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
