How to operate
Starting HDMI DIAGNOSTICS Mode
1
Turn on the AV Receiver.
If a malfunction occurs, HDMI DIAGNOSTICS mode can be started without
turning off the power.
2
Press and hold the main unit's buttons [A] and [B] at least 3
seconds until "HDMI DIAGNOSTICS" appears on the front panel
display.
Model Button [A] Button [B]
AVR-S730H
AVR-S930H
AVR-X1400H
AVR-X2400H
ZONE2
SOURCE
TUNER
PRESET CH -
0
Front panel display sample (e.g. AVR-X2400H)
.
0
HDMI DIAGNOSTICS mode cannot be entered from the Setup Menu or Setup
Assistant. Close the menu first.
3
When starting the HDMI DIAGNOSTICS mode, the AV Receiver
will automatically start the Hardware Self Diagnostics Test to
check whether hardware failure occurs.
If there are no errors, the AV Receiver will show the HDMI Diagnostics menu
on the front panel display.
If the hardware error is detected, the AV Receiver will show an error code on
the front panel display. (e.g. H1-01)
In this case, the AV Receiver can not continue the HDMI Diagnostics mode.
Please turn off the AV Receiver and contact customer service in your area.
（For contact service, refer to “Customer Support” (v
p. 9)）
0
Front panel display sample (e.g. AVR-X2400H)
.
HardwareCheck...
Err: H1-01
Contact support
Hardware Error detected
Blink
Introduction How to operate Cable Test Limit mode Log & EDID Troubleshooting
