Denon AVR-X3200W Service Manual

YES
YES
YES
In the same way as for Network connection troubleshooting, check the
CY920 power supply and Ethernet SBL, and that the IMG version is displayed
correctly.
Is the Wi-Fi/BT antenna cable inserted correctly into CY920?
Is the Bluetooth device compatible with the A2DP prole?
Is the Bluetooth function enabled on the Bluetooth device?
Connect the Wi-Fi/BT antenna cable correctly.
Use a device that is A2DP prole compatible.
Enable the Bluetooth function and try connecting
again.
NO
NO
NO
5.2. Cannot connect to the Bluetooth
Checking the unit
Check the Bluetooth
100

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
