Denon AVR-X3200W Service Manual

WIRING DIAGRAM
SMPS PCB
INLET
FRONT VFD PCB
FRONT H D MI PCB
TUNER PACK
AMP PCB
D IGITAL PCB
MAIN TRANS
WIRING DIAGRAM
FUNCT ION ENCOD ER,
VOLUME ENCO DER
CUP12779Z
FUSE PCB
CUP12765Z
CUP12627Z-3
CUP12764Z
USB JACK PCB
FL601
CUP12774Z-1
MIC
CUP12774Z-2
POW ER LED PCB
CU P12774Z-5
(AVRX3200W)
CUP12774Z-4
W iFi Antenna
W iFi Antenna
W AFER/2P/3 .96m m
CN901
CJP02KA060ZY
W AFER/2P/7 .92m m
CN902
CJP02GA89ZY
(PRI.)
W IRE/5P /3.96mm/220m m
(AMP PW R)
(S1)
Ne tw ork PCB
W iFi Antenna W iFi Antenna
CJP40GA193ZY
CN69B
FFC W A FER/40P/1m m
CN321
W AFER/5P/2 m m
CJP05GI288ZY
CJP
40GB284ZN
CN69A
FFC W A FER/40P/1m m
(S5/S6)
W IRE/7P /2.5mm/270m m
(FL PW R)
W IRE/4P /2.5mm/220m m
(S3/S4)
W IRE/3P /2.5mm/300m m
(S2)
CN706 BN461
CUP12771Z
INPUT PCB
VID EO PCB
CUP12766Z
SPK, REG. PCB
CUP12627Z-1
(S3/S4)
W AFER/9P/2 m m
CN932
CJP09GI288ZY
CJP05GI289ZY
W AFER/5P/2 .5m m
CN940
BN701
BN702
W AFER/7P/3 .96m m
CN971
CJP07GA90ZY
78127907 7807 7905 78057805
FRONT CNT. PCB
CUP12769Z
SID E CNT.PCB
CUP12770Z
CJP07GB03ZY
W AFER/7P/2 .5m m
CN602
BN321
CW B8 A005450H C
UL2725# 24/# 28,1P+ 2 C U SB
W IRE/5P /2mm/450m m
CUP12771Z-3
CN431
CJP23GA193ZY
(FRONT H D MI)
FFC W A FER/23
P/1m m
CON2
CON1
BN703
CW B7 E0071803D
UL1569# 20,105
BN702
BN701
CW B7 E0042203D
W IRE/5P /2.5mm/220m m
UL1569# 20,105
UL1569# 20,105
UL1007# 26
W IRE/9P /2mm/220m m
BN932
CN704
W AFER/6P/2 .5m m
CJP06GI289ZY
CN702
W AFER/5P/2 .5m m
CJP05GI289ZY
CN703
W AFER/7P/2 .5m m
CJP07GI289ZY
CJP13GI288ZY
CN461
W AFER/13P/2m m
CN701
W AFER/4P/2 .5m m
CJP04GI289ZY
W IRE/7P /2mm/180m m
UL1007# 26
BN710
CW B1 B007180LC
H EAD PH ONE PCB
CU P12774Z-3
BN461
CN706
CJP03GI288ZY
W IRE/13P/2 mm/180m m
CW B1 B013180H C
W AFER/3P/2 m m
W IRE/7P /2.5mm/180m m
W IRE/4P /2.5mm/220m m
CW B7 E0052203D
CW B1 B009220H C
W IRE/2P /3.96mm/130m m
FFC W A FER/23P/1m m
CJP23GA193ZY
FRO NT H D M I PCB
CN101
CW B7 D 006350AGD
W IRE/6P /2.5mm/350m m
BN901
W AFER/6P/2 .5m m
(D IGITAL PO W ER)
CJP06GA353ZJ
CN903
CN704
CJP07GA208ZY
(7CH AMP)
W AFER/7P/2 m m
BN706
UL1569# 24,105
W IRE/3P /2mm/100m m
CW B7 C003100H C
UL1569# 20,105
W IRE/6P /2.5mm/400m m
BN704
CW B7 E0064003D
Bridge D io de
(S2)
CN941
W AFER/3P/2 .5m m
CJP03GI289ZY
CN101
118

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
