Denon AVR-X3200W Service Manual

BK903
OPTION
OPTION
OPTION
AC220~240V : 100uF/400V AC100~120V : 220uF/200V
HEATSINK
(16.5*16*30)
AC100 ~ 120V
AC220 ~ 240V
OPTION
OPEN
CCQF2E104KZE-T
HEATSINK
(15*17*30)
CMY6A025
CMY3A238
CMD1A629
OPTION
OPTION
OPTION
R9004 330K(0.2W)
C9006
0.1uF(1608)
C9007
0.1uF(1608)
C9008
0.1uF(1608)
C9010
0.1uF(1608)
R9006
1M(1608)
D9006 1N4007
D9005 1N4007
D9001 1N4007
D9002 1N4007
D9003 1N4007
D9004 1N4007
CX902
0.1uF/275VAC
R9015
5.6K
R9016
12K
R9014
270K(1608)
R9010
1M(0.2W)
R9008
2.2M(0.2W)
ZD908
120V/5W
R9009
2.2M(0.2W)
ZD911
150V/5W
C9012
DC1KV/2200pF
R9017
6.8(0.2W)
C9017
47/25V(NXA)
D9013
1N4007
ZD920
39V
C9016
0.
1uF(1608)
D9008
1N4007
ZD918
27V
C9009 50V/10uF(NXA)
C9018 0.1uF(1608)
C9019 4.7uF(1608)
C9020 5600uF/6.3V
C9021 5600uF/6.3V
C9022 5600uF/6.3V
C9028
2200P 250V
C9029
0.1uF(1608)
R9019
2
3
1
D9012
SR3060PT
C9002 0.01uF 250V
C9003
0.01uF 250V
R9030
OPEN(1608)
C9030 OPEN(1608)
C9004
400V/100uF
R9035
1M(2125)
R9036
1M(2125)
R9037
1M(2125)
43
2 1
IC902
PC123Y22
ZD921
7.5V
J9002
JUMPER
J9003
JUMPER
D
G
S
Q9001
INK0010AC1
C9031
OPEN
GND91
OPEN
D S F C
X V
7 5 4 3 2 1
IC901
TOP268EG
1
2
3
4
5
6 7
8
9
10
11
12
T9001
J9001
OPEN
C9013
50V/1000pF(3216)
C9014
50V/1000pF(3216)
R9013
3216/22ohm
R9038
10(3216)
C9032
47pF/1KV
ZD9017
39V
D9009 1N4007
After primary side rectification
(Caution: High voltage, electric shock)
After secondary rectifications
A B
C
Primary drain
(Caution: High voltage, electric shock)
Operation waveform for each part
A B C
A B C
SMPS unit
(Unloaded)
Set
104

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
