Denon AVR-X3200W

Pin Pin Name Symbol
I/O Pu/Pd STBY STOP
CEC
STBY
Function
19
XCIN XCIN
I Pd - - -
NC(Pull down)
20
XCOUT XCOUT
I - - -
NC(open)
21
RES# RESET
I - - -
Reset input
22
XTAL/P37 XTAL
I - - -
Oscillator connection(12MHz)
23
VSS VSS
- - - -
GND
24
EXTAL/P36 EXTAL
- - - -
Oscillator connection(12MHz)
25
VCC VCC
- - - -
POWER pin
26
UPSEL/P35(IN)/NMI DSP FLAG3
I Pd I I I
DSP control pin
27
P34/SCK6/SCK0/IRQ4 BDOWN
I I I I
Power failure detection pin
28
P33/TIOCD0/RXD6/
RXD0/IRQ3-DS
RC IN
I I I I
Remote control signal input pin
29
P32/TIOCC0/TXD6/TXD0/
IRQ2-DS
NC
O/I L/I L/I L/I
NC
30
TMS/PF3 NC
I/I M3VPu -/I -/I I
Unused
31
TDI/PF2/RXD1 NC
I/O/I M3VPu -/-/I -/-/I I
Unused
32
P31/IRQ1-DS TU GPO2_INT
I L L L
TUNER control pin
33
P30/RXD1 TU SDIO
I_O SW3VPu L L L
TUNER control pin
34
TCK/FINEC/PF1/SCK1 NC
I/I/I M3VPu -/-/I -/-/I I
Unused
35
TD0/TXD1/PF0 NC
O/O/I M3VPu -/-/I -/-/I I
Unused
36
P27/SCK1 TU SEN
O L L L
TUNER control pin
37
P26/TXD1 TU SCLK
O L L L
TUNER control pin
38
P25/RXD3 TU RST
O SW3VPu L L L
TUNER control pin
39
VCC VCC
- - - -
POWER pin
40
P24/SCK3 NC
O L L L
NC
41
VSS VSS
- - - -
GND
42
P23/TXD3 E SPI CS
O N3VPu L L L
ETHERNET communication control pin(CY920)
43
P22/SCK0 E SPI CLK
O N3VPu L L L
ETHERNET communication control pin(CY920)
44
P21/RXD0/IRQ9 E SPI MIEO
I N3VPu I L I
ETHERNET communication control pin(CY920)
45
P20/TXD0/IRQ8 E SPI MOEI
O N3VPu L L L
ETHERNET communication control pin(CY920)
46
P17/SCK1/TXD3/IRQ7 E SPI REQ
I Pd I L I
ETHERNET communication control pin(CY920)
47
P87/TXD10/TIOCA2 NC
O L/H L/L L/H
NC
48
P16/TXD1/RXD3/IRQ6 E RESET
O(ODR) N3VPu L L L
ETHERNET RESET control pin(CY920)
49
P86/RXD10
PRE Z2
MUTE(X2200)/
NC(S910)
O L L L
ZONE2 PRE OUT MUTE control pin
50
P15/RXD1/SCK3/IRQ5 AEXP STB
O L L L
EXPANDER control pin
51
P14/IRQ4 AEXP OE
O L L L
EXPANDER control pin
52
P13/TXD2/IRQ3 AEXP CLK
O L L L
EXPANDER control pin
53
P12/RXD2/IRQ2 AEXP DATA
O L L L
EXPANDER control pin
54
VCC_USB VCC_USB
- - - -
POWER pin
55
USB0_DM USB0_DM
- - - -
NC(open)
56
USB0_DP USB0_DP
- - - -
NC(open)
57
VSS_USB VSS_USB
- - - -
GND
58
AVCC_USBA AVCC_USBA
- - - -
POWER pin
59
USBA_PREF USBA_PREF
- - - -
NC(open)
60
AVSS_USBA AVSS_USBA
- - - -
GND
61
PVSS_USBA PVSS_USBA
- - - -
GND
62
VSS2_USBA VSS2_USBA
- - - -
GND
63
USBA_DM USBA_DM
- - - -
NC(open)
64
USBA_DP USBA_DP
- - - -
NC(open)
65
VSS1_USBA VSS1_USBA
- - - -
GND
66
VCC_USBA VCC_USBA
- - - -
POWER pin
67
P11/SCK2/IRQ1 CEC_OUT
O L L -
CEC-D signal output pin
68
P10/IRQ0 CEC_IN
I SW3VPu I I I
CEC-D signal input pin
69
P53 ADV8003 SPI CS
O L L L
GUI control pin(ADV8003)
70
P52/RXD2 ADV8003 SPI MI
I L L L
GUI control pin(ADV8003)
71
P51/SCK2 ADV8003 SPI CLK
O L L L
GUI control pin(ADV8003)
72
P50/TXD2 ADV8003 SPI MO
O L L L
GUI control pin(ADV8003)
73
VSS VSS
- - - -
GND
74
P83/SCK10 IP_RST
O Pd I I L
HDMI ADV8003 RESET control pin
75
VCC VCC
- - - -
POWER pin
76
UB/PC7/TXD8/IRQ14 NC
I Pd - - -
Unused
77
PC6/RXD8/IRQ13 AVSDA
I_O DV3VPu O/L O/L L
VIDEO I2C- ADV8003/ADV7850
78
PC5/SCK8 AVSCL
I_O DV3VPu O/L O/L L
VIDEO I2C- ADV8003/ADV7850
79
P82/TXD10 DSP MOSI
O DA3VPu L L L
DSP control pin
80
P81/RXD10 DSP MISO
I DA3VPu L L L
DSP control pin
81
P80/SCK10 DSP CLK
O DA3VPu L L L
DSP control pin
82
PC4/SCK5 DSP CS
O DA3VPu L L L
DSP control pin
