Denon AVR-X3200W Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q'ty New Ver
C4219 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CL10A475KQ8NNNC CCUS0J475KCS 1
C4220-4223 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 4
C4301-4335 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 35
C4336,4337 nsp CAP, CHIP(1608, 50V/9pF, C0G)_SAMSUNG CL10C090CB8ANNC CCUS1H090DAS 2
C4338 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 1
C4339-4349 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 11
C4350 nsp CAP,ALUMINUM ELECTROLYTIC CAPACITORS(16V/100uF) MVG SERIES CCEC1CMVG101T 1
C4353-4361 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 9
C4371-4373 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 3
C4374,4375 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 2
C4381-4384 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CL10A475KQ8NNNC CCUS0J475KCS 4
C4406,4407 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 2
C4411,4412 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CL10A475KQ8NNNC CCUS0J475KCS 2
C4417,4418 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CL10A475KQ8NNNC CCUS0J475KCS 2
C4420,4421 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CL10A475KQ8NNNC CCUS0J475KCS 2
C4423,4424 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CL10A475KQ8NNNC CCUS0J475KCS 2
C4425 nsp CAP,ALUMINUM ELECTROLYTIC CAPACITORS(16V/100uF) MVG SERIES CCEC1CMVG101T 1
C5001 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C5002 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 1
C5011,5012 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CL10A475KQ8NNNC CCUS0J475KCS 2
C5013,5014 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 2
C5021,5022 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CL10A475KQ8NNNC CCUS0J475KCS 2
C5023,5024 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 2
C5031,5032 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CL10A475KQ8NNNC CCUS0J475KCS 2
C5033,5034 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 2
C5041,5042 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CL10A475KQ8NNNC CCUS0J475KCS 2
C5043,5044 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 2
C5091 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C5092,5093 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 2
C5094 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C5101 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C5111 nsp CAP, CHIP(1005, 25V/0.022uF, X7R)_SAMSUNG CL05B223KA5NNNC CCUI1E223KCS 1
OTHER PARTS GROUP
BK101-103 nsp BRACKET , PCB CMD1A569-V1 3
BK104 nsp BRACKET , CY920 CMD1A924 1
BN21A nsp PIN SOCKET (19P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP19HJ282Z 1
BN23A,24 nsp PIN SOCKET (27P,1.25mm,ANGLE,B-TO-B) C125Z2/COSMOS CJP27HJ282Z 2
BN25A nsp PIN SOCKET (23P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP23HJ282Z 1
BN26A nsp PIN SOCKET (09P,1.25mm,ANGLE,B-TO-B) C125Z2/COSMOS CJP09HJ282Z 1
BN27A nsp PIN SOCKET (15P,1.25mm,ANGLE,B-TO-B) C125Z2/COSMOS CJP15HJ282Z 1
CN152 nsp WAFER, FFC, SMD(11P-1mm, STRAIGHT) CJP11GA193ZY 1
CN221 nsp WAFER, FFC, SMD(07P-1mm, STRAIGHT) CJP07GA193ZY 1
CN251-253 nsp WAFER, FFC, SMD(07P-1mm, STRAIGHT) CJP07GA193ZY 3
CN321 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/5PIN SMW200-05 CJP05GI288ZY 1
CN401 nsp WAFER, FFC, SMD(07P-1mm, STRAIGHT) CJP07GA193ZY 1
CN431 nsp WAFER, FFC, SMD(23P-1mm, STRAIGHT) CJP23GA193ZY 1
CN501,502 nsp WAFER, 64pin ( 2 x 32 x 1.27mm) MALE SMD TYPE S1210-64SVB-S01-1RYN CJP64GA321ZP 2
CN511,512 nsp WAFER, FFC, SMD(07P-1mm, STRAIGHT) CJP07GA193ZY 2
CN69B nsp WAFER, FFC, SMD(40P-1mm, STRAIGHT) CJP40GA193ZY 1
CN704 nsp WAFER, 2mm, SMD, Vertical, 07p 20022WS-NN SERIES CJP07GA208ZY 1
CN903 nsp WAFER, STRAIGHT 2.5MM DIP 06P B6B-EH-A CJP06GA353ZJ 1
JK201 943643101110S JACK, 2P(ORG),SILVER RCA-215A-00-01/YUQIU CJJ4N068Y 1
JK202,203 943262100150S MODULE , OPTICAL(RX 16MHz) CJSJSR1124 2
JK381-384 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) A0D7ABAR1990 CJJ9H021Z 4
JK391-394 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) A0D7ABAR1990 CJJ9H021Z 4
JK431 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) A0D7ABAR1990 CJJ9H021Z 1
JK501 943643102430S JACK , RJ-45 W/TRANSFORMER KRJ-015XXNL CJJ9L029Z 1
L1001-1006 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 6
L1008 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1009 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 1
L1010 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1011-1013 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 3
L1014,1015 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 2
L1016-1020 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 5
L1022-1025 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 4
L1029-1034 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 6
L1111 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1113,1114 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 2
L1121 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1124 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1131 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1134 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1141 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1144 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1151 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1154 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1161 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1164 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1171 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1174 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1181 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1184 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1191 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1194 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1201 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1204 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
L1211-1213 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATAMURATA CLZBLM21PG221S
N
3
L1214 nsp FERRITE CHIP BEAD(2012/120R) BLM21AG121SN1/MURATAMURATA CLZBLM21AG121S
N
1
L1215 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 1
L2501-2503 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 3
L3501-3513 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATAMURATA CLZBLM21PG221S
N
13
L3801,3802 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATAMURATA CLZBLM21PG221S
N
2
L3804-3806 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATAMURATA CLZBLM21PG221S
N
3
L3808 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATAMURATA CLZBLM21PG221S
N
1
L3809,3810 nsp BEAD , FERRRITE CHIP(16OHM/32X16 SIZE) FBMJ3216HL160NT CLZFBMJ3216HL16
0
2*
L3901,3902 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATAMURATA CLZBLM21PG221S
N
2
L3904-3906 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATAMURATA CLZBLM21PG221S
N
3
L3908 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATAMURATA CLZBLM21PG221S
N
1
L3909 943113100000S COMMON MODE FILTER (1210, 90ohm) EXC24CH9000U CLZ9Z188Z 1
L3910,3911 nsp BEAD , FERRRITE CHIP(16OHM/32X16 SIZE) FBMJ3216HL160NT CLZFBMJ3216HL16
0
2*
L4001-4010 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 10
L4012-4016 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 5
L4301 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATAMURATA CLZBLM21PG221S
N
1
L4303-4305 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATAMURATA CLZBLM21PG221S
N
3
L4307,4308 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATAMURATA CLZBLM21PG221S
N
2
L4309,4310 nsp BEAD , FERRRITE CHIP(16OHM/32X16 SIZE) FBMJ3216HL160NT CLZFBMJ3216HL16
0
2*
L4311-4313 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 3
L4314 943113100000S COMMON MODE FILTER (1210, 90ohm) EXC24CH9000U CLZ9Z188Z 1
L5091 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T 1
L5111,5112 nsp COMMON MODE FILTER (2012, 90ohm) EXC34CE900U CLZ9Z174Z 2
ST01 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
ST04,05 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 2
SW501 90M-SS000710R SWITCH , SLIDE KSS2B016Z 1
14

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
