EXPLODED
EXPLODED
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
C1 nsp FRONT PCB COP12774M-1
┗C4 - FRONT HDMI FFC CABLE PCB COP12774M-6
C31 nsp SPK PCB COP12627T-1
┣C29 - FUSE PCB COP12627T-3
┣C7 - GUIDE L PCB COP12627T-5
┗C15 - FFC PCB COP12627T-6
C20 nsp SMPS PCB COP12765B
C14 nsp VIDEO PCB COP12766M-1
┗C10 - FRONT FFC PCB COP12766M-2
C28 nsp FRT CNT PCB COP12769M-1
C30 nsp SIDE CONT PCB COP12770M-1
C11 nsp INPUT PCB COP12771M
┗C5 - FRT HDMI PCB COP12771M-3
C8 nsp AMP PCB COP12779M
C16 9U6391023900S
DIGITAL PCB
•Change the resistor for setting the region.
•地域を設定するための抵抗を変更します。
(See PROCEDURE AFTER REPLACING THE PRINTED CIRCUIT BOARDS. )
(
基板を交換した場合
の
対応
について
を参照
)
COP12764M *
C2-BN321 nsp WIRE ASS'Y (5P,2.0mm,450mm,UL2725#24/#28,1P+2C)USB CWB8A005450HC CWB8A005450HC 1 *
C3 943606502870S CARD CABLE(1mm/40P/270mm/B/SHIELD) CWC4F2A40A270B08002 CWC4F2A40A270B
0
1*
C6 943606502880S CARD CABLE(1mm/23P/290mm/B/SHIELD) CWC4F2A23A290B10001 CWC4F2A23A290B1 1 *
C9 nsp WIRE ASS'Y (7P,2.0MM,180MM,UL1007#26) CWB1B007180LC CWB1B007180LC 1
C12 nsp WIRE ASS'Y Locking (YH) (13P,2MM,180MM,#26) CWB1B013180HC CWB1B013180HC 1
! C13 943101102520D TRANS , POWER(EI96 X 65) SH10149 E3 CLT5V068ZU 1
! C13 943101102530D TRANS , POWER(EI96 X 65) SH10147 E2 CLT5V068ZE 1
! C13 943101102540D TRANS , POWER(EI96 X 65) SH10148 E1C CLT5V068ZH 1
C17 9R1891003003D CY920 MODULE ASSY (7200E3) CNVCY920-C 1
C18 - 2P WIRE ASS'Y(100MM) CWZPM5003TW91
A
1
! ┣C18-RT01 00MYJ0400264
0
RECEPTACLE , AC
(
15A/250V,R-301,B21
)
R-301
(
B21
)
CJJ8A006ZW 1
┗C18-TW91 ns
p
2P WIRE ASS'Y
(
100MM
)
CWZPM5003TW91 1
C19a 963116100530S WIFI ANT(L) : wire 450mm E600506600010S 1
C19b 963116100540S WIFI ANT(R) : wire 300mm E600505600010S 1
C21 - CONDENSER TO SMPS-C9020 CCEA0JNXA562ES
C22 - CONDENSER TO SMPS-C9021 CCEA0JNXA562ES
C23 - CONDENSER TO SMPS-C9022 CCEA0JNXA562ES
C24 - WIRE ASS'Y TO SMPS-BN901 CWB7D006350AGD
C25 - TRANS TO SMPS-T9001 CLT9Z119ZE
C26 - CONDENSER TO SMPS-C9004 CCET200NHA221ES
C27 - LINE FILTER TO SMPS-LF901 CLZ9Z176Z
C32 - CONDENSER TO SPK-C9705 CCET71VLKS123N
C33 - CONDENSER TO SPK-C9706 CCET71VLKS123N
C34 - WIRE ASS'Y TO SPK-BN706 CWB7C003100HC
C35 - WIRE ASS'Y TO SPK-BN704 CWB7E0064003D
C36 - WIRE ASS'Y TO SPK-BN703 CWB7E0071803D
C37 - WIRE ASS'Y TO SPK-BN701 CWB7E0042203D
C38 - WIRE ASS'Y TO SPK-BN702 CWB7E0052203D
C39 - WIRE ASS'Y TO SPK-BN932 CWB1B009220HC
M1 42141003400AD BADGE , DENON E3 CGB1A275Z 1
M1 42141002400AD BADGE , DENON E2/E1C CGB1A254Z-V1 1
M2 42131003300AD BADGE , INCOMEND E3 CGB1A276Z 1
M3 943403101120D CABINET , TOP CKC3A155K117 1
M4 nsp EARTH , PHONE CMC1A476 1
M5 nsp PLATE , SHIELD CMC1A485 1 *
M6 nsp EARTH , USB CMD1A843 1
M7 nsp CHASSIS , BOTTOM CUA7A330 1 *
M8 nsp HEATSINK CMY1A372-V1
M9 nsp BRACKET , PCB (AMP) CMD1A796
M10 nsp SMPS BRACKET CMD1A790 1
M11 nsp PCB BRACKET(HDMI) CMD1A791 1
M12 nsp PANEL , REAR E3 CKF2A499Z 1 *
M12 nsp PANEL , REAR E2 CKF3A499Z 1 *
M12 nsp PANEL , REAR E1C CKF3A499Y 1 *
M13 - HEATSINK TO SMPS-IC901 CMY7A025
M14 - HEATSINK TO SMPS-D9012 CMY3A238
M15 - SHEILD , TRANS COVER TO SMPS-★ CMC1A445
M16 nsp NUT -2
M17 nsp WASHER -2
P1 963412100880D KNOB , FUNCTION CBN1A279 1
P2 963412100860D KNOB , VOLUME CBN1A280 1
P3 963451101200D SHEET , FUNCTION KNOB CGX1A485 1
P4 963451101190D SHEET , VOLUME KNOB CGX1A486 1
P5 963424100330D RING , FUNCTION KNOB CGR1A554 1
P6 963424100310D RING , VOLUME KNOB CGR1A555 1
P7 943416101380D WINDOW , DISPLAY E3 CGU1A475Y 1
P7 943416101390D WINDOW E2/E1C CGU1A475X 1
P8 943402105650S E3 PANEL ASS'Y E3 CGW2A558YA 1 *
P8 943402105660S E2 PANEL ASS'Y E2,E1C CGW1A558YA 1 *
P9 943423100540D INDICATOR , POWER CGL1A306A36 1
P10 943411102530D BUTTON , POWER CBT1A1183 1
P11 963411101780D BUTTON , 10KEY CBT1A1184 1
P12 nsp CUSHION , EVA CHG1A590 2
P13 963407100420D FOOT CKL1A225 4
P14 00D9630214607 CUSHION , FOOT CHG2A289 4
P15 nsp RUBBER CHG1A113 5
P16 nsp HOLDER , PCB CHE170 3
P17 nsp SUPPORT, PCB CRE1A102 1
P18 nsp SPACER , PCB CRE1A132 1 *
P19 nsp SUPPORT , RUBBER CHG1A535 1
P20 963419100910S BUSH , WIFI ANTENNA CMH1A357 2
P21 963419100920S HOLDER , WIFI ANTENNA CMH1A358 2
P22 963419100930S CLIP , WIFI ANTENNA CMH1A360 2
P23 nsp ORNAMENT , REAR PANEL A CGX1A487Z 1
P24 nsp LABEL , POP E3 CQB1A1397Z 1 *
P24 nsp LABEL , POP E2 CQB1A1398Z 1 *
P24 nsp LABEL , POP E1C CQB1A1399Z 1 *
P25 nsp LABEL , LICENSE E3 CQB1A1295Z 1
P25 nsp LABEL , LICENSE E2/E1C CQB1A1296Z 1
P26 nsp LABEL , SPOTIFY E3/E2 CQB1A1299Z 1
P27 nsp LABEL , DTS X FRONT CQB1A1438Z 1 *
★ nsp LOCKER SH08M790BO E2/E1C CRE1A037 22
BK601 nsp BRACKET , FIP CMD1A572-V1 1
BK602 nsp BRACKET , FIP CMD1A572-V1 1
BK603 nsp BRACKET , PCB CMD1A629 1
SCREW
S1 nsp SCREW CTB3+8JFZR 8
27
