Denon AVR-X3200W Service Manual

1.5. Version Display in the Setup Menu
Follow the steps below to display the rmware information.
(1) Press the "
SETUP
" button on the remote control.
(2) Select "General - Information - Firmware".
The version information is displayed as a 12-digit number as shown in the screenshot below.
This 12-digit number comprises a part of the version number of each device and module.
These version numbers correspond to the 14-digit number as shown below.
b
The rmware version numbers and this 12-digit version information are written in the Service Information.
General/Firmware
Version
XXXX - XXXX - XXXX
GUI Image
Main
M.FBL
X X 3 8
Info display
1 2 0 0 - 8 3 8 2 - 6 7 7 3
DSP X X X 2
A.PLD
V.PLD
X X X 1
X X X 7
GUI X X X X X X X 6
X X X X
X X 2 8
X X X X
E.FBL X X X X X X
E.SBL B X X X X X X X X X X X X
E.IMG I X X X X X X X X 0 0 3 7
The 1st digit from the right for DSP
The 1st digit from the right for A.PLD
The 1st digit from the right for IMG
The 2nd digit from the right for IMG
The 1st digit from the right for GUI
The 1st digit from the right for V.PLD
The 2nd digit from the right for Main
The 1th digit from the right for Main
The 2nd digit from the right for Sub
The 1st digit from the right for Sub
22

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
