Denon AVR-X3200W Service Manual

3.5. DIAGNOSTICMODE(ServicePathCheckMode)
3.5.1.Actions
This function is convenient for conrming problem paths in the product and executing a path check after repair.
The Video and Audio paths can be checked.
The backup data is not rewritten.
3.5.2.Startingup
Hold down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" at the same time and press the power button to turn on the power.
Select the mode using the button "
TUNER PRESET CH+
", and press the button "
STATUS
" to commit the selection.
Select "
1. SERVICE CHECK
" and press the "
STATUS
" button to start the diagnostic mode.
The "
TUNED
", "
STERO
" and "
RDS
" segments are lit in this mode.
3.5.3.Cancelingdiagnosticmode
Press the power button to turn off the power.
3.5.4.Selectingitems
Press
q
button to switch between video items and audio items.
Press button
w
or
e
to select the previous or next item.
The unit Remote control unit
Actions
q w e q w e
Audio ⇔ Video PREVIOUS NEXT Audio ⇔ Video PREVIOUS NEXT
Button DIMMER QUICK SELECT 1 QUICK SELECT 2 SLEEP CURSOR LEFT CURSOR RIGHT
3.5.5.Videosystemconrmationitems
g. XX: See the block diagram of the g.XXth.
Paths conrmation item Display Settings Contents of conrmation Remarks
1
Analog Video
V 0 1 : V I D E O P A S S
Input Source : CBL/SAT
Video Convert(IP Scaler) : OFF, All sources
MAIN ZONE : ON
ZONE2 : ON
・Component input ⇒ Component output (E3 ONLY)
( ※ As the input source, you can switch from CBL/SAT to other ones.
2
Video Convert
(Analog or HDMI ⇒ HDMI)
V 0 2 : V . C O N V E R T
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE ON
ZONE2 OFF
・Check of CVBS input ⇒ IP Scaler ⇒ HDMI output.
・Check of Component input ⇒ IP Scaler ⇒ HDMI output.
・Check of HDMI input ⇒ IP Scaler ⇒ HDMI output.
・Check of ETHERNET input ⇒ IP Scaler ⇒ HDMI output.
（※ The input source can be switched to any source except CBL/SAT.）
3
HDMI pass
（MAIN ZONE）
V 0 3 : H D M I P A S S
Input Source : CBL/SAT
Source of Video Convert(IP Scaler) : OFF, All sources
MAIN ZONE ON
ZONE2 OFF
・Check of HDMI input（MAIN Function）⇒ HDMI output（MAIN）
（※ The input source can be switched to any source except CBL/SAT.）
4
HDMI CEC
V 0 4 : H D M I C E C
Input Source : CBL/SAT
HDMI Control : ON
MAIN ZONE ON
ZONE2 OFF
・ When the power supply of a TV is put in the standby mode, make sure that the power supply of this unit is also put
in the standby mode.
・The ARC path can also be checked (check this using the TV input source).
（※ The input source can be switched to any source except CBL/SAT.）
5
HDMI Audio
(Audio: AVR)
V 0 5 : H . A U D I O - A V R
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio：AVR ( if checking the audio output from AVR )
・Check of HDMI input(PCM , DolbyDigital , DTS) ⇒ Speaker output.
・Check of HDMI input(HD audio) ⇒ Speaker output.
（※ The input source can be switched to any source except CBL/SAT.）
6
HDMI Audio
(Audio: TV)
V 0 6 : H . A U D I O - T V
HDMI Audio：TV ( if checking the audio output from TV ) ・Check of HDMI input(PCM , DolbyDigital , DTS) ⇒ HDMI output (audio output from connected TV)
（※ The input source can be switched to any source except CBL/SAT.）
7
GUI
V 0 7 : G U I M E N U O N
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "AUTO", All sources
Setup Menu ON
MAIN ZONE ON
ZONE2 OFF
・Check of GUI display ⇒ HDMI output.
（※ The input source can be switched to any source except CBL/SAT.）
8
HDMI
(ZONE2)
V 0 8 : Z O N E 2 H D M I
Input Source : CBL/SAT
ZONE2 Source : Source
MAIN ZONE : ON
ZONE2 : ON
・HDMI input (ZONE2 Function) ⇒ HDMI output (ZONE2)
( ※ As the input source, you can switch from CBL/SAT to other ones.)
g.01
g.02a
g.02b
g.03
g.04
g.05a
g.05b
g.05c
g.06a
g.06b
g.07
g.08
26

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
