Denon AVR-X3200W Service Manual

YES
YES
YES
YES
Check the TV.
(12) Does the TV support HDCP?
(14) Is HDMI input set on the TV?
(15) Are a picture and sound output when a different TV is used?
Check the unit.
Check the rmware.
Is "
IP SCALER NG
" displayed?
(See 21 page)
(13) Does the TV support 1080P/4K?
Use a TV that supports HDCP. Computer monitors can-
not be used.
Check the instruction manual of the TV and check the
input setting.
The TV is faulty.
•Check the circuits around the IP SCALER (IC401, DIGI-
TAL PCB) and DDR2 (IC402/403).
If there appear to be no problems, IC401 or IC402/403
is faulty.
If the TV does not support 1080P/4K, a picture cannot be
output even if the Blu-ray/DVD player is set to 1080P/4K.
NO
NO
NO
YES
NO
See "AVR-X3200W_HDMI Rx-Tx Failure Detection Procedure Manual
ver_1.00" of SDI.
NO
NO
(11) Are a picture and sound output when a different Blu-ray/DVD
player is used?
The Blu-ray/DVD player is faulty.
YES
94

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
