Pin Pin Name Symbol I/O Pu/Pd STBY STOP
CEC
STBY
Function
133
PE2/RXD12/IRQ7-
DS/AN100
AIOS4_STBY_
STATUS
I
-
I I I
Not used (This port use to detect for Network Module
standby status in the future (Low：normal, High：Deep
Standby))
134 PE1/TXD12 GUI_WRITE O L L L GUI ash rom writing control
135 PE0/SCK12
NET3.3V_
POWER
O L L L Ethernet power supply control(Net3.3V)
136 P64 D5V_POWER O L L H
Digital 5V power supply control pin(3.3V and 1.8V gener-
ate from 5V)(When CEC standby mode3,set to Low)
137 P63 CEC_POWER O L L H
CEC standby power supply
control(CEC5V,CEC3.3V,CEC1.8V)(When CEC standby
mode3,set to Low)
138 P62 DV_POWER1 O L L L Digital video power supply (DV5V,DV3.3V) control pin
139 P61 DV_POWER2 O L L L Digital video power supply (DV1.8V) control pin
140 VSS VSS - - - - Ground pin
141 P60 DIR_DIN O L L L DIR (PCM9211) control pin
142 VCC VCC - - - - Power supply pin
143 PD7/IRQ7/AN107 DIR_CE O L L L DIR (PCM9211) control pin
144 PG1 DIR_DOUT I
DA3.3Pu
I I I DIR (PCM9211) control pin
145 PD6/IRQ6/AN106 DIR_CLK O L L L DIR (PCM9211) control pin
146 PG0 DIR_RST O L L L DIR (PCM9211) control pin
147 PD5/IRQ5/AN113 787_HAINT I
CEC3VPu
Z - HDMI Rx (MN864787) audio interrupt signal det
148 PD4/IRQ4/AN112 DSP4CS O
DA3VPu
Pd Z L DSP(ADI) control pin
149 P97 DE_RST O
Pd
Z L Video decoder (ADV7180) reset control pin
150 PD3/IRQ3/AN111 787_HINT I
CEC3VPu
Z - HDMI Tx (MN864787) interrupt signal input pin
151 VSS VSS - - - - Ground pin
152 P96 787_RST O
Pd
Z H
HDMI Tx (MN864787) reset control pin (When CEC
standby mode3,set to reset)
153 VCC VCC - - - - Power supply pin
154 PD2/IRQ2/AN110 788_2_HINT I
CEC3VPu
Z - HDMI Rx (MN864788) interrupt signal input pin
155 P95 788_2_RST O
Pd
Z H
HDMI Rx (MN864788) reset control pin (When CEC
standby mode3,set to reset)
156 PD1/IRQ1/AN109 788_1_HINT I
CEC3VPu
Z - HDMI Rx (MN864788) interrupt signal input pin
157 P94 788_1_RST O
Pd
Z H
HDMI Rx (MN864788) reset control pin (When CEC
standby mode3,set to reset)
158 PD0/IRQ0/AN108 ARC_RST O
Pd
L L L Reset control pin for ARC IC
159 P93/AN117
THERMAL_
A(X4500H/
SR7013)/
NC(AV7705)
I
SW3VPu
I L I Protection detect signal input pin (for power TR)
160 P92/RXD7/AN116 DA_POWER1 O L L L Digital audio power supply (DA3.3V,DA1.2V) control pin
161 P91/AN115
THERMAL_
E(X4500H/
SR7013)/
NC(AV7705)
I/I
SW3VPu
I/I L I/I Protection detect signal input pin (for Heat sink)
162 VSS VSS - - - - Ground pin
163 P90/TXD7/AN114
TEMP_SEN-
SOR
I I L I Temperature sensor input pin (for SRM)
164 VCC VCC - - - - Power supply pin
165
P47/IRQ15-DS/
AN007
ARC_INT I
IOVc-
c3VPu
L L L ARC IC interrupt signal input pin
166
P46/IRQ14-DS/
AN006
CURRENT_
DET(X4500H/
SR7013)/
NC(AV7705)
I/O I/L L/L I/L Current level monitor pin (A/D converter)
167
P45/IRQ13-DS/
AN005
AMPSIGDET(X4500H/
SR7013)/NC(AV7705)
I I L I Signal level monitor pin (AD converter)
168
P44/IRQ12-DS/
AN004
MODE I I I I Region setting pin
169
P43/IRQ11-DS/
AN003
KEY3 I
M3VPu
I I I
Key control signalinput pin (When standby mode,set to
inturrupt)
170
P42/IRQ10-DS/
AN002
KEY2 I
M3VPu
I I I
Key control signalinput pin (When standby mode,set to
inturrupt)
Pin Pin Name Symbol I/O Pu/Pd STBY STOP
CEC
STBY
Function
171
P41/IRQ9-DS/
AN001
KEY1 I
M3VPu
I I I
Key control signalinput pin (When standby mode,set to
inturrupt)
172 VREFL0 VREFL0 - - - - Ground pin
173 P40 SEL_CLK O L L L Audio selector control pin (NJU72750/72751)
174 VREFH0 VREFH0 - - - - Power supply pin
175 AVCC0 AVCC0 - - - - Power supply pin
176 P07/IRQ15 DSP2FLAG3 I
Pd
L L L DSP(ADI) control pin
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
65
