The circuit of Network Module is faulty.
Are the versions of the HEOS Version displayed in
Version Check Mode?
The Network Module software is faulty.
In the same way as for Network connection troubleshooting, check the Network Module power supply
and HEOS Version is displayed correctly.
Is the antenna cable inserted correctly into Net-
work Module?
Is the Bluetooth device compatible with the A2DP
prole?
Is the Bluetooth function enabled on the Blue-
tooth device?
Connect the antenna cable correctly.
Use a device that is A2DP prole compatible.
Enable the Bluetooth function and try connecting
again.
5.2. Cannot establish a Bluetooth connection
Checking the unit
Check the Bluetooth device being used
YES
NO
NO
NO
NO
YES
YES
YES
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
97

Denon AVR-X4500H Specifications

General

Display	-
Quantity	1
HDCP version	2.2
Apple docking	No
Product color	Silver
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
Audio amplifier	Yes
Multi-Zone quantity	3
Connector contacts plating	Gold
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (20-20KHz@8 Ohm)	125 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
HDMI in	8
Audio (L/R) in	5
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	13500 g
