Denon AVR-X540BT Service Manual

USB
REF No. Part No. Part Name Remarks Q'ty New Ver
C1403 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C1405 nsp CAP,ALUMINUM ELECTROLYTIC (16V/10uF) CCEC1CMVG100T 1
C1406 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1407 nsp CAP,ALUMINUM ELECTROLYTIC CAPACITORS(16V/100uF) CCEC1CMVG101T 1
C1408 nsp CAP, CHIP(1608, 50V/27pF, C0G)_SAMSUNG CCUS1H270JAS 1
C1410 nsp CAP,ALUMINUM ELECTROLYTIC (16V/10uF) CCEC1CMVG100T 1
C1411 nsp CAP,ALUMINUM ELECTROLYTIC (16V/10uF) CCEC1CMVG100T 1
C1413 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1414 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1415 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C1416 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1417 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9010 nsp CAP,ALUMINUM ELECTROLYTIC (6.3V/220uF) CCEC0JMVG221T 1
C9011 nsp CAP,ALUMINUM ELECTROLYTIC (6.3V/220uF) CCEC0JMVG221T 1
C9012 nsp CAP,ALUMINUM ELECTROLYTIC (6.3V/47uF) CCEC0JMVG470T 1
C9014 nsp CAP,ALUMINUM ELECTROLYTIC (16V/10uF) CCEC1CMVG100T 1
C9015 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9016 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9017 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9018 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9019 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9020 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9021 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9022 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9023 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9026 nsp CAP, CHIP(1608, 50V/2200pF, X7R)_SAMSUNG CCUS1H222KCS 1
C9027 nsp CAP, CHIP(1608, 50V/2200pF, X7R)_SAMSUNG CCUS1H222KCS 1
C9028 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9029 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C9030 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C9033 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 1
C9034 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 1
C9035 nsp CAP, CHIP(1608, 6.3V/2.2uF, X7R)_SAMSUNG CCUS0J225KCS 1
C9036 nsp CAP, CHIP(1608, 6.3V/2.2uF, X7R)_SAMSUNG CCUS0J225KCS 1
C9039 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9040 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9041 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9042 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9043 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9044 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9045 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9046 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9047 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9048 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9049 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9050 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9051 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9052 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9053 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9054 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9055 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9056 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9058 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9059 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9060 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9061 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9062 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9063 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9064 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C9065 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C9066 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C9067 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C9068 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C9069 nsp CAP, CHIP(1005, 50V/10pF, C0G)_SAMSUNG CCUI1H100JAS 1
C9072 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9073 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9074 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9075 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9076 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9077 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9078 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9079 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9080 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9081 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9082 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9083 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9084 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9085 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 1
C9086 nsp CAP, CHIP(1005, 50V/15pF, C0G)_SAMSUNG CCUI1H150JAS 1
C9087 nsp CAP, CHIP(1005, 50V/15pF, C0G)_SAMSUNG CCUI1H150JAS 1
C9088 nsp CAP, CHIP(1005, 50V/220pF, C0G)_SAMSUNG CCUI1H221JAS 1
C9089 nsp CAP, CHIP(1005, 50V/220pF, C0G)_SAMSUNG CCUI1H221JAS 1
C9090 nsp CAP, CHIP(1005, 50V/33pF, C0G)_SAMSUNG CCUI1H330JAS 1
C9091 nsp CAP, CHIP(1005, 50V/33pF, C0G)_SAMSUNG CCUI1H330JAS 1
C9092 nsp CAP, CHIP(1005, 50V/33pF, C0G)_SAMSUNG CCUI1H330JAS 1
C9093 nsp CAP, CHIP(1005, 50V/33pF, C0G)_SAMSUNG CCUI1H330JAS 1
C9094 nsp CAP, CHIP(1005, 50V/47pF, C0G)_SAMSUNG CCUI1H470JAS 1
C9095 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9096 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9097 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9098 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9099 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9100 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9103 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9109 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9110 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9111 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9112 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9113 nsp CAP,ALUMINUM ELECTROLYTIC (16V/10uF) CCEC1CMVG100T 1
C9114 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9115 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9116 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9117 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9118 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9119 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9120 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9121 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9122 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9123 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9124 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9125 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9126 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9127 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9128 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9129 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9130 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
OTHER PARTS GROUP
BN912 nsp WIRE ASS'Y Locking (YH-CKM)15P,2MM,280MM,#26,105'C VWB7B015280HC 1 *
BN914 nsp WIRE ASS'Y Locking(YH-CKM)7P,2.0MM,280MM,#26,105'C VWB7B007280HC001 1 *
2

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
