Denon AVR-X540BT Service Manual

USB
REF No. Part No. Part Name Remarks Q'ty New Ver
CN911 nsp WAFER , CARD CABLE (SMD, 09P-1mm, ANGLE, H : 2mm) CJP10GB310ZY 1
JK105 943643102930S JACK, STEREO, 3.5mm MINI, BLACK MOLD CJJ2D029Z 1
JK91 943643101590S JACK, USB STRAIGHT(BLACK 1.5A) CJJ9X010Z 1
L1401 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L9010 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
L9011 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
L9013 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
L9014 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
L9015 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
L9018 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
L9019 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
L9023 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L9024 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L9026 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
L9027 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
X9001 943141100610S X-TAL, SMD 3.2X2.5, 12.000MHz, 10PF COX12000I100ST 1
3

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
