Denon AVR-X540BT Service Manual

MAIN
REF No. Part No. Part Name Remarks Q'ty New Ver
R5218 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5219 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5220 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5221 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5222 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5223 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5224 nsp RES, CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5225 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5226 943252101120S PTC THEMISTORS, CHIP(85'C)
CRTDHPTF1608471P85T
1*
R5227 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5229 nsp RES, CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5230 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5231 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5232 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R5301 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5302 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R5303 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5304 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R5305 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5306 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R5307 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R5308 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5309 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5310 nsp RES, M-OXIDE FILM(1W/47ohm) CRG1SANJ470RT 1
R5313 nsp RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5314 nsp RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5315 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5316 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5317 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5318 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5319 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5320 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5321 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5322 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5323 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5324 nsp RES, CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5325 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5326 943252101120S PTC THEMISTORS, CHIP(85'C)
CRTDHPTF1608471P85T
1*
R5327 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5329 nsp RES, CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5330 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5331 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5332 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R5401 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5402 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R5403 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5404 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R5405 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5406 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R5407 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R5408 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5409 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5410 nsp RES, M-OXIDE FILM(1W/47ohm) CRG1SANJ470RT 1
R5413 nsp RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5414 nsp RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5415 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5416 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5417 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5418 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5419 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5420 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5421 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5422 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5423 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5424 nsp RES, CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5425 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5426 943252101120S PTC THEMISTORS, CHIP(85'C)
CRTDHPTF1608471P85T
1*
R5427 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5429 nsp RES, CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5430 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5431 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5432 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R5501 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5502 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R5503 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5504 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R5505 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5506 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R5507 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R5508 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5509 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5510 nsp RES, M-OXIDE FILM(1W/47ohm) CRG1SANJ470RT 1
R5513 nsp RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5514 nsp RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5515 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5516 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5517 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5518 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5519 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5520 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5521 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5522 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1
R5523 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5524 nsp RES, CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5525 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5526 943252101120S PTC THEMISTORS, CHIP(85'C)
CRTDHPTF1608471P85T
1*
R5527 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5529 nsp RES, CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5530 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5531 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5532 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R5701 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5702 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5703 nsp RES, M-OXIDE FILM(1W/33ohm) CRG1SANJ330RT 1
R5704 nsp RES, M-OXIDE FILM(1W/100ohm) CRG1SANJ101RT 1
R5705 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5706 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5711 nsp RES, CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 1
R5712 nsp RES, CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 1
R5713 nsp RES, CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 1
R5715 nsp RES, M-OXIDE FILM(1W/2.2Kohm) CRG1SANJ222RT 1
R5716 nsp RES, M-OXIDE FILM(1W/2.2Kohm) CRG1SANJ222RT 1
R5717 nsp RES, M-OXIDE FILM(1W/2.2Kohm) CRG1SANJ222RT 1
R5721 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R5722 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R5723 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R5724 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R5725 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R5726 nsp RES, M-OXIDE FILM(2W/470ohm) CRG2SANJ471RT 1
7

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
