Denon AVR-X540BT Service Manual

MAIN
REF No. Part No. Part Name Remarks Q'ty New Ver
R5727 nsp RES, M-OXIDE FILM(2W/470ohm) CRG2SANJ471RT 1
R5728 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R5817 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5818 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5819 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7801 nsp RES, CHIP(1608/5%/1.8Kohm) CRJ10DJ182T 1
R7802 nsp RES, CHIP(1608/1%/82ohm) CRJ10DF82R0T 1
R7803 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R7804 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R7806 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7807 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1
R7808 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1
R7809 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7810 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7811 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7812 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
CAPACIITORS GROUP
C5101 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C5102 nsp CAP, MYLAR(100V/470pF/J) HCQI2A471JZT 1
C5103 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5104 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5105 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C5106 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5107 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C5108 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5109 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5201 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C5202 nsp CAP, MYLAR(100V/470pF/J) HCQI2A471JZT 1
C5203 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5204 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5205 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C5206 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5207 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C5208 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5209 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5301 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C5302 nsp CAP, MYLAR(100V/470pF/J) HCQI2A471JZT 1
C5303 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5304 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5305 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C5306 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5307 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C5308 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5309 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5401 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C5402 nsp CAP, MYLAR(100V/470pF/J) HCQI2A471JZT 1
C5403 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5404 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5405 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C5406 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5407 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C5408 nsp CAP , ELECT(63V/100uF)
CCEA1JH101T 1
C5409
nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5501 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C5502 nsp CAP, MYLAR(100V/470pF/J) HCQI2A471JZT 1
C5503 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5504 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5505 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C5506 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5507 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C5508 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5509 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5605 nsp CAP, MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5606 nsp CAP, MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5607 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5608 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5609 nsp CAP, MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5610 nsp CAP, MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5611 nsp CAP, MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5612 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5613 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5614 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5701 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1
C5702 90M-OF100490R CAP, METAL PE FILM(250V/0.1uF) KCME2E104JP04T 1
C5703 90M-OF100490R CAP, METAL PE FILM(250V/0.1uF) KCME2E104JP04T 1
C5704 943134010460S CAP , ELECT (30X35) WITHOUT PLATE ON THE TOP CCET63VKL5682NKZ 1
C5706 943134010460S CAP , ELECT (30X35) WITHOUT PLATE ON THE TOP CCET63VKL5682NKZ 1
C5707 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C5708 943134010480S CAP, ELECT(100V/100uF) CCEA2AH101E 1
C5710 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5711 nsp CAP, ELECT(6.3V/470uF) CCEA0JH471T 1
C5716 nsp CAP, ELECT(16V/47uF) CCEA1CH470T 1
C5717 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C5718 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5719 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5720 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5721 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5722 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5723 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C7714 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7715 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7801 nsp CAP, CHIP(1608, 50V/22pF, C0G)_SAMSUNG CCUS1H220JAS 1
C7804 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C7805 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C7806 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7807 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7810 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C7811 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C7812 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7813 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C7814 nsp CAP, CHIP(1608, 50V/33pF, C0G)_SAMSUNG CCUS1H330JAS 1
C7815 nsp CAP, CHIP(1608, 50V/33pF, C0G)_SAMSUNG CCUS1H330JAS 1
OTHER PARTS GROUP
BK501 nsp BRACKET , PCB CMD1A569-V1 1
BN501 nsp WIRE ASS'Y Locking (YH) (15P,2MM,150MM,#26) VWB1B013150HC 1 *
BN502 nsp WIRE ASS'Y Locking (YH) (9P,2MM,150MM,#26) VWB1B009150HC 1 *
BN505 nsp WIRE ASS'Y Locking(YH-CKM)3P,2.0MM,220MM,#26,105'C VWB7B003220HC 1 *
BN508 nsp PIN HEADER (09P,1.25mm,STRAIGHT,B-TO-B) CJP09GI281Z 1
CN503 nsp WAFER , 7P(DIP, 3.96PITCH) CJP07GA90ZY 1
CN510 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN520 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN530 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN540 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN550 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN781 nsp WAFER, FFC(9P-1mm, STRAIGHT) CJP09GA117ZY 1
ET501 nsp PLATE , EARTH(TRONIC ELECTRONICS) CJT1A026 1
JK503 943643102350S 4P PUSH SPK (RW/BB, NO SPCC, 94V-0) CJJ5P038Z 1
JK504 943643102360S 6P PUSH SPK (GBB/BBB, NO SPCC, 94V-0) CJJ5R021Z 1
JK781 90M-YT002940R JACK , BOARD CJJ4S010Z 1
8

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
