Denon AVR-X8500H Service Manual

1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
While holding down buttons "
SETUP
" and "
OPTION
" simultaneously, press the power button to turn
on the power.
then press the "
STATUS
" button to display the information in section 1.3 on the display.
b
The version list is also displayed on GUI while the version is displayed on the display.
1.3. Display Order
Error information(See "1.4. Error display") →
q
Model destination information, Serial Number
→
w
Firmware Package →
e
Main μ -com, Main 1st Boot Loader →
r
DSP1/2 ROM
→
t
Audio Video PLD →
y
GUI SFLASH →
u
HEOS Version →
i
HEOS Build →
o
HEOS Module
→
Q0
HEOS Conguration →
Q1
HEOS Locale →
Q2
Ether Mac Address →
Q3
WiFi Mac Address
→
Q4
BT Mac Address →
Q5
Audyssey App Interface Version
q
Model destination information, Serial Number：
L1
@@@-X8500H \\\
L2
SN**************
@
： Model name (AVR, AVC)
\
： Region (E3, E2, E1C, JP)
w
Firmware Package :
L1
Firm. Package
L2
Ver.:****
e
Main µ-com, Main 1st Boot Loader :
L1
M:*************
L2
Main FBL :**.**
r
DSP 1/2 ROM :
L1
DSP1 :**.**
L2
DSP2 :**.**
t
Audio, Video PLD :
L1
Audio PLD:**.**
L2
Video PLD:**.**
y
GUI SFLASH :
L1
GUI :@@$\****
@
: Model code
$
: Brand code (Non=0, De=1, Mz=2, Mc=3)
\
: Region code (E3=1, E2=2, E1C=5, JP=4, ALL=0)
*
: version
u
HEOS Version :
L1
HEOS Version
L2
*.***.***
i
HEOS Build :
L1
HEOS Build
L2
******
o
HEOS Module :
L1
HEOS Module
L2
***
Q0
HEOS Conguration :
L1
HEOS Config
L2
Development
Production
Q1
HEOS Locale :
L1
HEOS Locale
L2
*****
Q2
Ether Mac Address :
L1
*Ether MAC
L2
******-******
Q3
WiFi Mac Address :
L1
*Wi-Fi MAC
L2
******-******
Q4
BT Mac Address :
L1
*BT MAC Address
L2
******-******
Q5
Audyssey App Interface Version :
L1
Audy IFVer:**.**
L2
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
139

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
